DRUM BRAKE » DN1372
Specification
Outter Ø
262
Num. of holes
5
Hole Ø
12.6
Centering Diameter
62
Height
59.3
Pitch Circle Ø
114.3
Drum Ø
220
Structure Material
G3000
Cross Reference
SUZUKI
43511-80J00
SUZUKI
43511-80J00-000
SUZUKI
43511-80J01
SUZUKI
43511-80J01-000
| years | Eng | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 05.06~ | 1500 | M15A | YA11S | RN1320V | PN2201 | DN1372 | FN9801 | |
| 05.06~10.14 | 1500 | M15A | YB11S | RN1320V | PN2201 | DN1372 | FN9801 | |
| 06.07~ | 1500 | M15A | YC11S | RN1320V | PN2201 | DN1372 | FN9801 | |
| 07.06~03.16 | 1600 | M16A | GYA21S | RN1320V | PN2201 | RN1524RN1755DN1372 | PN8398FN9801 | |
| 06.06~12.15 | 1600 | M16A | GYC21S SDN | RN1320V | PN2201 | RN1755RN1524DN1372 | FN9801PN8398 | |
| 04.07~07.12 | 2000 | J20A | JS2YC4 SDN | RN1320V | PN2201 | RN1524DN1372 | FN9801PN8398 | |
| 07.09~04.14 | 2000 | J20B | JS2YC5 SDN | RN1320V | PN2201 | RN1524DN1372 | FN9801PN8398 | |
| 06.12~03.14 | 2000 | J20B | YB5A | RN1320V | PN2201 | DN1372RN1524 | FN9801PN8398 |
