ROTOR DISC » RN1038
Specification
Type
Solid
Disc Thickness (Max)
10
Num. of holes
5
Height
46
Centering Diameter
107
Front/Rear
Front
Pitch Circle Ø
139.7
Outter Ø
289.8
Drum Ø:
182.8
Disc Thickness (Min)
8
Structure Material
G3000
Cross Reference
BENDIX
561505B
GM
18027899
GM
19195867
GM
96058796
OEM
55211160A00
OEM
5521180A00
OEM
5551160A00
SANTANA
5521160A00
SUZUKI
5521160A00
SUZUKI
5521160A01
| years | Eng | Eng No | BodyBody | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 05.88~10.97 | 1600 | G16A | TA01W | RN1998VRN1038 | PN9301PN9298 | FN9947FN9942FN9934FN9955FN9937 | ||
| 08.90~11.97 | 1600 | G16A | TD01W | RN1038RN1998V | PN9301PN9298 | FN9937FN9955FN9947FN9942 |
| 03.90~10.95 | 660 | F6A-T | JA11C | RN1038 | PN9118 | FN9921 | ||
| 11.95~10.98 | 660 | F6A-T | JA12C | RN1038 | PN9118 | FN9921 | ||
| 11.95~10.98 | 660 | F6A-T | JA12V | RN1038 | PN9118 | FN9921 | ||
| 10.98~11.04 | 660 | K6A | JB23W | RN1658RN1038 | PN9118 | DN1405 | FN5524 | |
| 11.95~10.98 | 660 | K6A# | JA22W | RN1038 | PN9118 | DN1361 | FN9921 | |
| 05.93~12.97 | 1300 | G13B | JB31W | RN1038 | PN9118 | FN9921 | ||
| 05.93~12.97 | 1300 | G13B | JB32W | RN1038 | PN9118 | FN9921 | ||
| 01.98~04.00 | 1300 | G13B | JB33W | RN1038 | PN9118 | DN1405 | FN5524 | |
| 10.98~10.02 | 1300 | G13BB | JB33V | RN1038 | PN9118 | DN1405 | FN5524 | |
| 07.12~05.19 | 1300 | M13A | JB4# LHD | RN1658RN1038 | PN9118 | DN1405 | FN5524 | |
| 10.98~08.05 | 1300 | M13A | JB43V LHD | RN1038 | PN9118 | DN1405 | FN5524 | |
| 10.98~07.12 | 1300 | M13A | JB43V RHD | RN1658RN1038 | PN9118 | DN1405 | FN5524 | |
| 01.98~ | 1300 | M13A | JB43W JPN | RN1038 | PN9118 | DN1405 | FN5524 |
