ROTOR DISC » RN1998V

RN1998V

Specification

Type
Vented
Outter Ø
287
Num. of holes
5
Disc Thickness (Max)
17
Height
46.1
Centering Diameter
107
Pitch Circle Ø
140
Drum Ø:
183
Disc Thickness (Min)
15
Structure Material
G3000

Cross Reference

BENDIX
562075B
GM
30012150
SUZUKI
55211-56B00
SUZUKI
55211-56B01
SUZUKI
55211-76J10
SUZUKI
55211-76J11
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

SUZUKI   »   Escudo

05.88~10.97 1600 G16A TA01W RN1998VRN1038 PN9301PN9298 FN9942FN9934FN9955FN9937FN9947
08.90~11.97 1600 G16A TD01W RN1998VRN1038 PN9298PN9301 FN9955FN9947FN9942FN9937

SUZUKI   »   Vitara

01.95~01.99 1600 G16B TD01V RN1998V PN9301 FN9942
