DRUM BRAKE » DN1363

DN1363

Specification

Outter Ø
262
Num. of holes
5
Hole Ø
12
Centering Diameter
50.1
Height
61
Pitch Circle Ø
139.7
Drum Ø
220
Structure Material
G3000

Cross Reference

GM
18028486
GM
19176942
GM
96058636
SUZUKI
43511-60A00
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

SUZUKI   »   Sidekick

04.89~01.98 1600 G16A SE416 PN9298PN9301 DN1420DN1363DN1364 FN9937FN9942FN9947

SUZUKI   »   Vitara

01.89~01.98 1300 G13B# SE413 PN9298 DN1363 FN9934
01.88~01.95 1600 G16A TA01C RN1038 PN9298 DN1363 FN9937
