DRUM BRAKE » DN1420

Specification

Outter Ø
313
Num. of holes
5
Centering Diameter
100
Height
65.8
Pitch Circle Ø
139.7
Drum Ø
254
Structure Material
G3000

Cross Reference

BENDIX
PDR0684
GM
30016444
MAZDA
1A50-26-251
SUZUKI
43511-77E00
SUZUKI
43511-77E00-000
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
01.95~11.97 2000 RF-T TJ31W PN9382 DN1420 FN9947
04.89~01.98 1600 G16A SE416 PN9298PN9301 DN1420DN1363DN1364 FN9942FN9947FN9937
01.96~01.98 1800 SV418 DN1420DN1364
01.94~08.99 2000 H20A TD11V PN9382 DN1420 FN9947
01.96~08.99 2000 J20A TA51V PN9382 DN1420 FN9947
11.94~08.99 2000 RF SV420D PN9382 DN1420 FN9947

Exemption from liability: the catalog data is advisory and can be used for reference only
