NiBK Brakes:: Application Cross Reference and Image for NiBK : ROTOR DISC : RN2034V

Product
Application

ROTOR DISC » RN2034V

Specification

Type

Vented

Outter Ø

256

Num. of holes

4

Disc Thickness (Max)

20

Height

45

Centering Diameter

64

Pitch Circle Ø

100

Disc Thickness (Min)

18.4

Drum Ø:

125

Structure Material

G3000

Hole Ø:

12.5

Front/Rear

Front

Notes

Thickness : 20

Cross Reference

MITSUBISHI

MR569931

MITSUBISHI

MR569932

years	Eng	Eng No	BodyBody	Front Rotor	Front Brake	Rear Rotor	Rear Brake	Parking Shoe

MITSUBISHI » Colt

10.04~07.12	1300	4A90	Z21A	RN2034V	PN3500	DN1356 DN1340	FN1267 FN6729
10.02~11.04	1300	4G19	Z25A	RN2034V	PN3500	DN1340	FN6729
10.02~10.04	1300	4G19	Z26A	RN2034V	PN3500	DN1340	FN6729
10.04~06.10	1500	4A91	Z23A	RN2034V	PN3500	DN1340 DN1356	FN1267 FN6729
10.02~06.12	1500	4A91	Z24A	RN2034V	PN3500	DN1340	FN6729
01.03~10.11	1500	4G15T	Z27A	RN2034V	PN3500	DN1340	FN6729
06.03~11.04	1500	4G15T	Z27A	RN2034V RN1944V	PN3500 PN3462 PN3126	RN1923 DN1340	PN3593 PN3314 FN6729

MITSUBISHI » Colt Plus

11.06~06.12	1300	4A90	Z21W	RN2034V	PN3500	DN1356	FN1267
05.10~06.12	1300	4A90	Z22W	RN2034V	PN3500	DN1340	FN6729
10.04~01.10	1500	4A91	Z23W	RN1944V RN2034V	PN3500 PN3462	DN1340 DN1356 RN1923	FN1267 PN3314 FN6729
10.04~07.12	1500	4A91	Z24W	RN2034V	PN3500	DN1340	FN6729
