DRUM BRAKE » DN1356

Specification

Outter Ø
240
Num. of holes
4
Hole Ø
12.5
Centering Diameter
64
Height
59.2
Pitch Circle Ø
100
Drum Ø
203
Structure Material
G3000

Cross Reference

MITSUBISHI
MN116750
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
10.04~07.12 1300 4A90 Z21A RN2034V PN3500 DN1340DN1356 FN1267FN6729
10.04~06.10 1500 4A91 Z23A RN2034V PN3500 DN1356DN1340 FN1267FN6729
11.06~06.12 1300 4A90 Z21W RN2034V PN3500 DN1356 FN1267
10.04~01.10 1500 4A91 Z23W RN1944VRN2034V PN3462PN3500 DN1340DN1356RN1923 FN1267PN3314FN6729

Exemption from liability: the catalog data is advisory and can be used for reference only
