BRAKE SHOE » FN0703

FN0703

Specification

Radius
105
Width
30
Thickness
4 / 6.5
Pcs In Set
4

Cross Reference

FMSI
S944-1597
LAND ROVER
LR021877
LAND ROVER
LR025151
LAND ROVER
LR031947
LAND ROVER
SFS500010
LAND ROVER
SFS500011
LAND ROVER
SFS500012
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

LAND ROVER   »   Discovery III

10.04~10.09 2700 276DT TAA PN0484 PN0485 FN0703
02.05~10.09 4000 406PN LA RN1940V PN0484 PN0485 FN0703
10.04~10.09 4400 AJ34 TAA PN0484 RN1732V PN0485 FN0703

LAND ROVER   »   Discovery IV

01.09~02.13 2700 276DT LA RN1940V PN0484 PN0485 FN0703
01.09~02.13 3000 306DT LA RN1728V PN0488 RN1732V PN0485 FN0703
07.12~12.18 3000 306DT LA RN1728V PN0488PN0488W RN1732V PN0485 FN0703
01.09~02.13 5000 508PN/AJ133 LA RN1728V PN0488 RN1732V PN0485 FN0703

LAND ROVER   »   Range Rover Sport

02.05~05.09 2700 276DT L320 RN1940V PN0484 PN0485 FN0703
05.10~03.13 3000 306DT LS RN1728V PN0488 RN1732V PN0485 FN0703
01.05~06.09 4200 428PS / AJ3 LS RN1728V PN47007 RN1732V PN0485 FN0703
01.05~06.09 4400 448PN / AJ4 LS PN0484 RN1732V PN0485 FN0703
07.09~03.13 5000 508PN/AJ133 L320 RN1728V PN0488WPN0488 RN1732V PN0485 FN0703
04.09~03.13 5000 508PS LS RN1733V PN0567 PN0566 FN0703
