ROTOR DISC » RN1940V

Specification

Type
Vented
Outter Ø
317
Num. of holes
5
Disc Thickness (Max)
30
Height
62
Centering Diameter
79
Pitch Circle Ø
120
Drum Ø:
165
Front/Rear
Front
Disc Thickness (Min)
27

Cross Reference

LAND ROVER
SDB000601
LAND ROVER
SDB000602
LAND ROVER
SDB000603
LAND ROVER
SDB000604
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
02.05~10.09 4000 406PN LA RN1940V PN0484 PN0485 FN0703
01.09~02.13 2700 276DT LA RN1940V PN0484 PN0485 FN0703
02.05~05.09 2700 276DT L320 RN1940V PN0484 PN0485 FN0703

Exemption from liability: the catalog data is advisory and can be used for reference only
