ROTOR DISC » RN1732V

RN1732V

Specification

Type
Vented
Num. of holes
5
Height
59
Pitch Circle Ø
120
Front/Rear
Rear
Outter Ø
350
Disc Thickness (Max)
20
Centering Diameter
79
Drum Ø:
210
Disc Thickness (Min)
17
Structure Material
G3000

Variation

RN1732DSET[NiBK]

Cross Reference

LAND ROVER
LR189034
LAND ROVER
SDB000642
LAND ROVER
SDB000643
LAND ROVER
SDB000644
LAND ROVER
SDB000645
LAND ROVER
SDB000646
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

LAND ROVER   »   Discovery III

10.04~10.09 4400 AJ34 TAA PN0484 RN1732V PN0485 FN0703

LAND ROVER   »   Discovery IV

01.09~02.13 3000 306DT LA RN1728V PN0488 RN1732V PN0485 FN0703
07.12~12.18 3000 306DT LA RN1728V PN0488PN0488W RN1732V PN0485 FN0703
01.09~02.13 5000 508PN/AJ133 LA RN1728V PN0488 RN1732V PN0485 FN0703

LAND ROVER   »   Range Rover Sport

05.10~03.13 3000 306DT LS RN1728V PN0488 RN1732V PN0485 FN0703
01.05~06.09 4200 428PS / AJ3 LS RN1728V PN47007 RN1732V PN0485 FN0703
10.05~04.09 4400 448PN L320 PN0484 RN1732V PN0485
01.05~06.09 4400 448PN / AJ4 LS PN0484 RN1732V PN0485 FN0703
07.09~03.13 5000 508PN/AJ133 L320 RN1728V PN0488WPN0488 RN1732V PN0485 FN0703
