ROTOR DISC » RN1728V

RN1728V

Specification

Type
Vented
Num. of holes
5
Front/Rear
Front
Outter Ø
360
Disc Thickness (Max)
30
Height
62
Centering Diameter
79
Pitch Circle Ø
120
Disc Thickness (Min)
27
Drum Ø:
175
Structure Material
G3000
Hole Ø:
15

Alternative

RN1760V[NiBK]

Cross Reference

LAND ROVER
LR019988
LAND ROVER
LR025946
LAND ROVER
SDB000621
LAND ROVER
SDB000622
LAND ROVER
SDB000623
LAND ROVER
SDB000624
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

LAND ROVER   »   Discovery IV

01.09~02.13 3000 306DT LA RN1728V PN0488 RN1732V PN0485 FN0703
07.12~12.18 3000 306DT LA RN1728V PN0488PN0488W RN1732V PN0485 FN0703
01.09~02.13 5000 508PN/AJ133 LA RN1728V PN0488 RN1732V PN0485 FN0703

LAND ROVER   »   Range Rover Sport

05.10~03.13 3000 306DT LS RN1728V PN0488 RN1732V PN0485 FN0703
10.06~03.13 3600 368DT L320 RN1728V PN0488PN47007 PN0485
01.05~06.09 4200 428PS / AJ3 LS RN1728V PN47007 RN1732V PN0485 FN0703
07.09~03.13 5000 508PN/AJ133 L320 RN1728V PN0488WPN0488 RN1732V PN0485 FN0703
