DRUM BRAKE » DN1480

DN1480

Specification

Outter Ø
316
Num. of holes
5
Hole Ø
14.3
Centering Diameter
75
Height
90
Pitch Circle Ø
120
Drum Ø
270
Structure Material
G3000

Cross Reference

HYUNDAI
58329-4A100
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

HYUNDAI   »   H1 Starex

05.97~09.04 2400 G4CS A1 RN1121VRN1951V PN0434 DN1477DN1480 FN0595
11.01~12.07 2400 L4CS A1 RN1951V PN0103PN0434 DN1480DN1481 PN0447

HYUNDAI   »   H100

03.93~09.03 2400 G4CS FD RN1095V PN0112 DN1515DN1458DN1480 FN1879FN0595
