DRUM BRAKE » DN1481

Specification

Outter Ø
343
Num. of holes
5
Hole Ø
14.3
Centering Diameter
75
Height
84.4
Pitch Circle Ø
120
Drum Ø
295
Structure Material
G3000

Cross Reference

HYUNDAI
58329-4A200
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
01.04~01.07 2400 G4JS WAGON SHORT - 9P RN1951V PN0103 DN1481 FN11002
09.06~09.07 2400 G4JS WGN LONG - 9P PN0103 DN1481 FN11002
11.01~12.07 2400 L4CS A1 RN1951V PN0103PN0434 DN1481DN1480 PN0447
06.00~09.04 2500 D4CB A1 WAGON SHORT - 9P RN1951V PN0103 DN1481 PN0447FN11002 FN11005

Exemption from liability: the catalog data is advisory and can be used for reference only
