DRUM BRAKE » DN1426

DN1426

Specification

Outter Ø
340
Num. of holes
6
Hole Ø
12.7
Centering Diameter
101
Height
80.5
Pitch Circle Ø
139.7
Drum Ø
295
Structure Material
G3000

Alternative

DN1124[NiBK]

Cross Reference

GREAT WALL
3502011-P00
ISUZU
8-97238-630-1
ISUZU
8-97360-506-0
ISUZU
8-98030-385-0
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

CHEVROLET (GM)   »   LUV

06.03~01.13 2400 LG1/C24SE DL33P RN24001VRN1327V PN4801 DN1426DN1439 FN4470FN4467

ISUZU   »   Alterra

03.05~10.13 3000 4JJ1-TC UCR85 RN1327V PN0822PN4801 DN1426 FN4467

ISUZU   »   D-Max

01.04~01.11 2500 4JA1-T TF_54 RN1327V PN0822 DN1426DN1439 FN4470FN4467
10.08~12.11 2500 4JK1-TCX TF_86 RN1327V PN0822 DN1426 FN4467
01.02~01.07 3000 4JH1 TFS77 RN1326VRN1327V PN4801 DN1426 FN4467
01.09~12.11 3000 4JJ1-TCS TFS85H RHD RN1327V PN0822 DN1426 FN4467
08.08~ 3000 4JJ1-TCS TF_85 RN1327V PN0822 DN1426 FN4467
06.03~ 3000 4JJ1-TCX TFS85 RN1327V PN4801 DN1426 FN4467

ISUZU   »   Pickup TFR

01.04~01.11 2500 4JA1-T TFS54H RN1327V PN4801 DN1426 FN4467
01.04~12.08 2500 4JK1-TCX TFR86 RN1327V PN4801 DN1426 FN4467
10.08~07.10 2500 4JK1-TCX TFR86 RN1327V PN0822 DN1426 FN4467
01.04~09.12 3000 4JH1-TC TFS77HDK RN1327V PN4801 DN1426 FN4467
01.04~12.11 3000 4JJ1-TCS TFS85H RHD RN1327V PN4801 DN1426 FN4467
