ROTOR DISC » RN24001V

RN24001V

Specification

Type
Vented
Outter Ø
256
Num. of holes
6
Disc Thickness (Max)
26
Height
40
Centering Diameter
88
Pitch Circle Ø
109
Front/Rear
Front
Drum Ø:
156
Disc Thickness (Min)
24,6
Structure Material
G3000

Cross Reference

GREAT WALL
3103101P01
ISUZU
8-97238-272-0
ISUZU
8-97308-868-0
ISUZU
8-97370-515-0
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

CHEVROLET (GM)   »   LUV

06.03~01.13 2400 LG1/C24SE DL33P RN1327VRN24001V PN4801 DN1426DN1439 FN4467FN4470

Great Wall Motors   »   Wingle

06.06~12.08 2800 GW28TC2 RN1395VRN24001V PN0502

ISUZU   »   Rodeo

01.03~ 3000 4JH1 TFR77 RN1327VRN24001V PN4801 FN4467FN4470
