ROTOR DISC » RN1403V
Specification
Type
Vented
Disc Thickness (Max)
24
Num. of holes
5
Height
45.6
Centering Diameter
69
Front/Rear
Front
Outter Ø
294
Drum Ø:
147.8
Pitch Circle Ø
114.3
Disc Thickness (Min)
22.4
Structure Material
G3000
Cross Reference
CITROEN
4249.58
MITSUBISHI
4615A006
MITSUBISHI
4615A113
MITSUBISHI
4615A179
MITSUBISHI
4615A189
MITSUBISHI
MR128659
MITSUBISHI
MR205215
MITSUBISHI
MR307376
Peugeot / Citroen
16 063 757 80
Peugeot / Citroen
16 114 298 80
Peugeot / Citroen
4249.59
Peugeot / Citroen
4249.F3
| years | Eng | Eng No | BodyBody | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 01.07~03.12 | 2000 | 4B11-MMC | EP | RN1403V | PN3233 | RN1402RN1404 | PN3450 | FN23001FN0625 |
| 02.07~09.12 | 2200 | DW12MTED4 | EP | RN1403V | PN3233 | RN1404 | PN3450 | FN0625 |
| 08.08~03.12 | 2400 | 4B12-MMC | EP | RN1403V | PN3233 | RN1404 | PN3450 | FN0625 |
| 10.07~03.16 | 2000 | 4B11 | CY4A | RN1403V | PN3233 | RN2004V | PN3450 | FN0625 |
| 08.07~03.16 | 2000 | 4B11-T | CZ4A | RN1403VRN1997V | PN0150WPN0150S | RN2004V | PN23002 | FN0625 |
| 01.07~12.17 | 2000 | 4B11 | CY4A | RN1366VRN1209VRN1403V | PN3469PN3233 | RN1404RN1367RN1402 | PN3450PN3502 | FN23001 |
| 10.09~10.12 | 2000 | 4B11 | CW4W EU LHD | RN1403V | PN3233 | RN1402 | PN3450 | FN23001 |
| 11.12~11.14 | 2000 | 4B11 | GG2W | RN1403V | PN3233 | RN1567 | PN25003 | |
| 01.03~12.08 | 2000 | 4G63 | CU2W | RN1403V | PN3233 | RN1242 | PN3502 | FN6704 |
| 07.12~ | 2000 | 4J11 | GF7W | RN2273VRN1403V | PN3233PN3813 | RN1567 | PN25003PN3815 | |
| 04.06~10.12 | 2000 | BSY | CW8W | RN1403V | PN3233 | RN1404RN1402 | PN3450 | FN0625FN23001 |
| 04.06~10.12 | 2200 | 4HK/4HN | CW7W | RN1403V | PN3233 | RN1404 | PN3450 | FN0625 |
| 01.12~ | 2300 | 4N14-T | GF6W | RN1403VRN1209V | PN3469PN3233 | RN1567 | PN3815PN25003 | |
| 08.13~04.22 | 2400 | 4B12 | GG3W | RN1403V | PN3813 | RN1567 | PN3815 | |
| 01.05~10.12 | 2400 | 4G69 | CU5W | RN1403VRN1365V | PN3233PN3469 | RN1242 | PN3502 | FN6704 |
| 10.02~12.08 | 2400 | 4G69 | CU5W EU | RN1403V | PN3233 | RN1242 | PN3502 | FN6704 |
| 11.06~04.12 | 3000 | 6B31 | CW6W | RN1209VRN1403V | PN3233PN3469 | RN1404RN1402 | PN3450 | FN23001FN0625 |
