ROTOR DISC » RN1242
Specification
Type
Solid
Disc Thickness (Max)
10
Num. of holes
5
Height
60
Centering Diameter
90
Pitch Circle Ø
114.3
Front/Rear
Rear
Outter Ø
262
Drum Ø:
168
Disc Thickness (Min)
8.5
Structure Material
G3000
Cross Reference
CHRYSLER
MB895200
CHRYSLER
MB928716
MITSUBISHI
MB928716
OEM
MR493489
| years | Eng | Eng No | BodyBody | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 05.02~09.05 | 2000 | 4G63-T | CU2W | RN1252V | PN3233 | RN1242 | PN3502 | FN6704 |
| 03.01~10.05 | 2400 | 4G64 | CU4W | RN1365V | PN3469 | RN1242DN1358 | PN3502FN6723 | FN6704 |
| 03.01~10.05 | 2400 | 4G64 | CU4W | RN1365V | PN3469 | DN1358RN1242 | FN6723PN3502 | FN6704 |
| 06.03~09.10 | 2400 | 4G69 | CU5W | RN1365V | PN3469PN3233 | RN1242 | PN3502 | FN6704 |
| 08.95~04.99 | 2000 | 4G63 | D32A | RN2078V | PN3271 | RN1242 | PN3174 | FN6704 |
| 05.96~09.98 | 2000 | 4G63-T | D38A | PN3271 | RN1242 | PN3174 | ||
| 05.96~10.00 | 2400 | 4G64 | D35A | PN3271 | RN1242 | PN3174 | ||
| 05.99~03.06 | 3000 | 6G72 | D53A | RN1252V | PN3233PN3469 | RN1242 | PN3174 | FN6704 |
| 01.76~02.80 | 1600 | G32B | E121A | RN1209V | PN3469 | RN1242 | ||
| 05.00~05.08 | 2000 | 4G94 | EA7A | RN1365V | PN3469 | RN1242 | PN3174 | FN6704 |
| 08.98~07.02 | 2400 | 4G64 | EA3A_JP | RN1365VRN1252V | PN3233PN3469 | RN1242 | PN3174 | FN6704 |
| 04.01~05.07 | 1800 | 4G93# | CS5A JPN | RN1365V | PN3462PN3469 | RN1242 | PN3502FN6729 | FN6704 |
| 01.00~12.07 | 1800 | 4G93# | CS5A RHD | RN1365V | PN3469 | RN1242DN1340 | FN6729PN3502 | FN6704 |
| 01.04~03.11 | 2000 | 4G63 | CS9A | RN1365V | PN3469 | RN1242 | PN3502 | FN6704 |
| 06.03~06.08 | 2000 | 4G63 | CS9W | RN1365V | PN3469 | RN1242 | PN3502 | FN6704 |
| 06.01~11.06 | 2400 | 4G69 | CS7A | RN1365VRN1237V | PN3469 | RN1242RN1158 | PN3502 | FN6704 |
| 01.03~12.08 | 2000 | 4G63 | CU2W | RN1403V | PN3233 | RN1242 | PN3502 | FN6704 |
| 01.05~10.12 | 2400 | 4G69 | CU5W | RN1365VRN1403V | PN3469PN3233 | RN1242 | PN3502 | FN6704 |
| 10.02~12.08 | 2400 | 4G69 | CU5W EU | RN1403V | PN3233 | RN1242 | PN3502 | FN6704 |
| 07.00~01.04 | 2000 | 4G94 | H67W | RN1256V | PN3417 | RN1242 | PN3174 | FN0808 |
| 09.00~02.05 | 2000 | 4G94 | H77W | RN1256V | PN3417 | RN1242 | PN3174 | FN0808 |
| 05.91~03.97 | 1800 | 4G93 | N21W | RN1106VRN2078VRN1011V | PN3271 | DN1349RN1242DN1354RN1158 | FN6687PN3174 | FN6704 |
| 05.96~03.97 | 1800 | 4G93 | N21WG | RN2078V | PN3271 | DN1354RN1242 | PN3174FN6687 | FN6704 |
| 01.91~11.97 | 2000 | 4G63 | N23W | RN2078V | PN3271 | RN1242 | PN3174 | FN6704 |
| 09.97~08.02 | 2000 | 4G63 | N73WG | RN2179V | PN3419 | RN1242 | PN3174 | FN6704 |
| 09.94~11.97 | 2000 | 4G63-T | N23WG | RN1252V | PN3233 | RN1242 | PN3174 | FN6704 |
