ROTOR DISC » RN1402

Specification

Type
Solid
Disc Thickness (Max)
10
Num. of holes
5
Height
60.5
Centering Diameter
80
Front/Rear
Rear
Pitch Circle Ø
114.3
Outter Ø
302
Drum Ø:
168
Disc Thickness (Min)
8.4
Structure Material
G3000

Cross Reference

CHRYSLER
04743 999AA
CHRYSLER
2AMV3 999AA
CHRYSLER
4615A010
CHRYSLER
4615A121
MITSUBISHI
4615A010
MITSUBISHI
4615A121
MITSUBISHI
4615A193
Peugeot / Citroen
16 062 920 80
Peugeot / Citroen
16 116 678 80
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
01.07~12.14 2400 ED3 JS RN1209V PN3469 RN1402 PN3502 FN23001
03.07~12.10 2000 RN1402
01.07~12.14 2400 ED3 JSZS41 RN1209V PN3469 RN1402 PN3450 FN23001
09.06~12.10 2700 EER JS RN1209V PN3469 RN1402RN1367 PN3502PN3450 FN23001
01.07~03.12 2000 4B11-MMC EP RN1403V PN3233 RN1402RN1404 PN3450 FN23001FN0625
06.07~12.14 2400 ED3 PN3469 RN1402 PN3502
01.07~12.10 2700 EER JSDP41 RN1209V PN3469 RN1402 PN3450 FN23001
05.06~06.09 2000 ECD PMBH49 RN1209V PN3469 RN1402 PN3450 FN23001
06.06~11.12 2000 ECN PM_H49 RN1209VRN1366V PN3469 DN1635RN1402 FN1264PN3450 FN23001
10.06~11.12 2400 ED3 PM RN1366V PN3469 RN1402RN1367 PN3450PN3502 FN23001
01.08~12.17 2000 ECE MK74 PN3469 RN1402 PN3502 FN23001
01.07~12.17 2400 ED3 MKJL74 RN1209V PN3469 RN1367RN1402 PN3450PN3502 FN23001
08.10~05.13 1600 4A92 GA1W RN1209V PN3469 RN1567RN1402 PN3450PN25003 FN23001
05.10~02.13 1800 4B10 GA3W RN1209V PN3469 RN1567RN1402 PN3450PN25003 FN23001
04.10~06.12 1800 4N13 GA6W RN1209V PN3469 RN1567RN1402 PN3450PN25003 FN23001
05.10~05.13 2000 4B11 GA2W RN1209V PN3469 RN1567RN1402 PN25003PN3450 FN23001
11.08~03.15 1800 4B10 CX3A RN1209V PN3469 RN1402 PN3450 FN23001
11.08~02.12 1800 4J10 CY3A RN1366VRN1209V PN3469 DN1355RN1402RN1367 PN3502PN3450FN1267 FN23001
12.08~03.15 2000 4B11-T CX4A RN1209V PN3469 RN1402 PN3450 FN23001
10.09~10.12 2000 4B11 CW4W EU LHD RN1403V PN3233 RN1402 PN3450 FN23001
06.09~09.12 2000 4B11 CW4W RHD RN1209V PN3469 RN1402 PN3450 FN23001
04.06~10.12 2000 BSY CW8W RN1403V PN3233 RN1404RN1402 PN3450 FN0625FN23001
09.05~09.12 2400 4B12 CW5W RN1209V PN3469 RN1402 PN3450 FN23001
09.05~09.12 2400 4B12 CW5W JPN RN1209V PN3469 RN1402 PN3450 FN23001
11.06~04.12 3000 6B31 CW6W RN1403VRN1209V PN3469PN3233 RN1404RN1402 PN3450 FN0625FN23001
07.10~06.12 2000 4B11 GA2W RN1209V PN3469 RN1402RN1567 PN25003PN3450 FN23001
02.10~10.12 1800 4B10 GA3W RN1209V PN3469 RN1402 PN3450 FN23001
10.11~09.12 1800 4J10 GA4W RN1209V PN3469 RN1402RN1567 PN3450PN25003 FN23001
08.12~11.22 1600 4A92 GA1W RN1209V PN3469 RN1402 PN3450
08.12~11.19 2000 4B11 GA2W RN1209V PN3469 RN1402 PN3450
12.18~11.22 2000 4J11 GA9W RN1209V PN3469 RN1402 PN3450

Exemption from liability: the catalog data is advisory and can be used for reference only
