NiBK Brakes:: Application Cross Reference and Image for NiBK : ROTOR DISC : RN3007V

ROTOR DISC » RN3007V

Specification

Type

Vented

Outter Ø

305

Num. of holes

5

Disc Thickness (Max)

28

Disc Thickness (Min)

26

Height

45.7

Centering Diameter

59

Pitch Circle Ø

98

Drum Ø:

127

Front/Rear

Front

Structure Material

G3000

Cross Reference

CHRYSLER

68201086AA

FIAT

51854567

FIAT

51897455

FIAT

51914663

FIAT

52067169

FIAT

52199580

GM

95515332

OPEL

05 69 096

OPEL

5 69 087

OPEL

95511283

years	Eng	Eng No	Body	Front Rotor	Front Brake	Rear Rotor	Rear Brake	Parking Shoe

FIAT » 500L

09.12~	1400	198 A4.000	312	RN3007V			PN41001W
01.13~	1400	312 B3.000	352	RN3007V	PN0748W		PN41001W

FIAT » Doblo Cargo

01.09~01.15	1600	198 A3.000	263.223.0.5	RN3007V	PN0187W	DN1697	FN41001
01.09~01.16	1600	263 A5.000	263.216.0.5	RN3007V	PN0748W PN0187W	DN1697	FN41001

FIAT » Doblo Panorama

02.10~

1400

843 A1.000

152.731.0.5

RN3007V

PN0748W

FN41001

FIAT » Nuovo Doblo

10.15~	1600	263 A5.000	263.216.1.5	RN1022V RN3007V	PN0187W PN0748W		FN41001
10.15~	1600	263 A5.000	263.226.1.5	RN3007V	PN0748W		FN41001
10.15~	1600	263 A8.000	263.223.1.5	RN3007V	PN0748W		FN41001

OPEL » Combo-D

01.12~01.18	1600	A16FDH	X12	RN3007V	PN0748W		FN41001
01.12~01.18	1600	A16FDL	X12	RN3007V	PN0748W		FN41001
