ROTOR DISC » RN2461V

RN2461V

Specification

Type
Vented
Outter Ø
231
Num. of holes
4
Hole Ø:
12.7
Disc Thickness (Max)
17
Disc Thickness (Min)
15
Height
40.2
Centering Diameter
60
Pitch Circle Ø
100
Front/Rear
Front
Structure Material
G3000

Cross Reference

SUZUKI
55311-52R00
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

SUZUKI   »   Swift V

01.20~ 1200 K12C A2L412-4 LHD ZC53S RN2461V PN9812 FN9806
01.17~ 1200 K12C ZC83S RHD RN2461V PN9812 FN9806
01.17~ 1200 K12M A2L412 LHD RN2461V PN9812 FN9806
01.17~ 1200 K12MS ZC63S LHD RN2393VRN2461V PN5562PN9812 RN2394 PN9808FN9806
