BRAKE SHOE » FN2306

FN2306

Specification

Radius
147
Width
60
Thickness
6.8
Pcs In Set
4

Cross Reference

TOYOTA
04495-60080
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

TOYOTA   »   Land Cruiser

08.23~ 2800 1GDFTV GDJ79R RN1604V PN1411 DN1225 FN2306
01.07~ 4000 1GR-FE GRJ71L RN1604V PN1411 DN1225RN1976V FN2306PN1243FN1179FN2280 FN0642
01.07~ 4000 1GR-FE GRJ76 FN2280FN2306FN1179
08.12~ 4000 1GR-FE GRJ78L RN1604V PN1411 RN1976VDN1225 FN2280PN1243FN1179FN2306 FN0642
01.07~ 4000 1GR-FE GRJ79R RN1604V PN1411 RN1976V FN2306FN2280PN1243FN1179 FN0642
01.90~09.23 4200 1H-Z HZJ71L RN1604V PN1411 RN1976VDN1225 FN2306FN1179PN1243FN2280 FN0642FN1179FN2280
01.90~01.04 4200 1H-Z HZJ71R FN2306FN1179FN2280
08.98~ 4200 1H-Z HZJ78R RN1604V PN1411 RN1976V PN1243FN1179FN2306FN2280 FN0642
08.99~09.17 4200 1H-Z HZJ79L RN1604V PN1411 RN1976VDN1225 FN1179FN2306FN2280PN1243 FN0642
08.16~ 4200 1H-Z HZJ79R DCB RN1604V PN1411 DN1225 FN2306
01.17~09.23 4500 1VD-FTV VDJ76L RN1604V PN1411 DN1225 FN2306
01.07~ 4500 1VD-FTV VDJ79R RN1604V PN1411 RN1976V FN1179FN2306FN2280PN1243 FN0642
