PERFORMANCE ROTOR DISC » RN1215DSET

Specification

Type 1:
Direction Vented
Disc Thickness (Max)
18
Num. of holes
5
Height
103
Centering Diameter
110
Front/Rear
Rear
Pitch Circle Ø
150
Outter Ø
329
Disc Thickness (Min)
16
Drum Ø:
230
Structure Material
GG20

Variation

RN1215V[NiBK]

Cross Reference

TOYOTA
42431-60220
TOYOTA
42431-60221
TOYOTA
42431-60280
TOYOTA
42431-60281
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
01.98~08.07 4700 2UZ-FE UZJ100 RN1224V PN1411 RN1215V PN1412 FN8905
01.98~08.07 4200 1HD-FT HDJ101K RN1224V PN1411 RN1215V PN1412 FN8905
01.98~09.07 4200 1HD-FTE HDJ100L RN1224V PN1411 RN1215VDN1224 PN1412FN2280FN1179 FN8905
08.00~08.07 4200 1HD-FTE HDJ100R RN1224V PN1411 RN1215V PN1412 FN8905
01.98~08.02 4200 1HD-T HDJ100R RN1224V PN1411 RN1215VDN1224 PN1412FN2280FN1179 FN8905
01.98~09.07 4500 1FZ-FE FZJ100 RN1224V PN1411 RN1215VDN1224 FN1179PN1412FN2280 FN8905
01.98~09.07 4700 2UZ-FE UZJ100L RN1224V PN1411 RN1215VDN1224 PN1412FN1179FN2280 FN8905
01.98~01.04 4700 2UZ-FE UZJ100R RN1224V PN1411 RN1215V PN1412 FN8905
01.98~08.07 4700 2UZ-FE UZJ100W RN1224V PN1411 RN1215V PN1412 FN8905

Exemption from liability: the catalog data is advisory and can be used for reference only
