DRUM BRAKE » DN1506

Specification

Outter Ø

220

Num. of holes

4

Hole Ø

12.5

Centering Diameter

62.5

Height

58

Pitch Circle Ø

100

Drum Ø

180

Structure Material

G3000

Cross Reference

KIA

58411-07000

years	Eng	Eng No	Body	Front Rotor	Front Brake	Rear Rotor	Rear Brake	Parking Shoe

KIA » Morning/Picanto 04

09.03~05.11	1100	D3FA	PSA	RN11001V	PN0438	DN1506	FN0618
09.03~12.07	1100	G4HG	NK07	RN11001V	PN0438	DN1506	FN0618
09.03~12.07	1100	G4HG	PSA04 RHD	RN11001V	PN0438	DN1506	FN0618

KIA » Morning/Picanto 08

12.07~04.10	1000	G4HE	PSA08 EU	RN11001V	PN0438	DN1506	FN0618
12.07~05.11	1000	G4HE	PSA08 KOREA	RN11001V	PN0438	DN1506	FN0618
12.07~05.11	1100	G4HG	BJ51 RHD	RN11001V	PN0438	DN1506	FN0618
12.07~05.11	1100	G4HG	BK51 LHD	RN11001V	PN0438	DN1506	FN0618
12.07~05.11	1100	G4HG	BK51 RHD	RN11001V	PN0438	DN1506	FN0618
12.07~05.11	1100	G4HG	PSA08	RN11001V	PN0438	DN1506	FN0618

KIA » Ray

11.11~	1000	G3LA	TAM	RN11001V	PN0580	RN1791 DN1506	PN0436
11.11~	1000	G3LB	TAM	RN2405V	PN0580	DN1506 RN1791	PN0436
