NiBK Brakes:: Application Cross Reference and Image for NiBK : DRUM BRAKE : DN1478

DRUM BRAKE » DN1478

Specification

Outter Ø

243

Num. of holes

4

Hole Ø

12.5

Centering Diameter

76

Height

58.8

Pitch Circle Ø

114.3

Drum Ø

203.2

Structure Material

G3000

Cross Reference

BENDIX

PDR0791

HYUNDAI

58411-17200

HYUNDAI / KIA

58411-17100

years	Eng	Eng No	Body	Front Rotor	Front Brake	Rear Rotor	Rear Brake	Parking Shoe

HYUNDAI » Avante / Elantra 00

06.00~03.06	1500	G4EB	XD		PN2245	DN1478 RN1130 DN1467	FN11158 PN2130
04.00~06.03	1500	G4EC	XD SDN		PN0542	DN1467 DN1478	FN11158
06.03~04.06	1500	G4EC	XD SDN		PN0542 PN2245	DN1478	FN11162 PN2130 FN11158
06.00~03.06	1800	G4BB	XD		PN2245	RN1130 DN1467 DN1478	PN2130 FN11158
04.00~03.06	2000	G4GC	XD	RN1230V	PN0788	DN1467 DN1478 RN1130	FN11158 PN2130

HYUNDAI » Matrix

02.01~12.08	1500	D3EA	FC		PN2245	DN1478	FN11158
02.02~01.11	1500	D4FA	FC		PN2245	DN1478	FN11158
02.01~11.06	1600	G4ED	PN81	RN1230V	PN0788	DN1478	FN11158
11.06~01.11	1600	G4ED	PN81	RN1230V	PN0788	DN1478	FN11158

HYUNDAI » Matrix-Lavita (FC)

02.01~11.06	1800	G4GB	PN81	RN1230V	PN0788	DN1478	FN11158
11.06~01.11	1800	G4GB	PN81	RN1230V	PN0788	DN1478	FN11158
