BRAKE SHOE » FN11162

Specification

Radius
90
Width
30
Thickness
4 / 6
Pcs In Set
4

Cross Reference

BENDIX AUS
BS1695
BENDIX AUS
BS1739
HYUNDAI
58305-02500
HYUNDAI
58305-02A00
HYUNDAI
58305-02A10
HYUNDAI
58305-05A00
HYUNDAI
58305-22A00
HYUNDAI
58305-22A01
HYUNDAI
58305-24000
HYUNDAI
58305-24020
HYUNDAI
58305-24A00
HYUNDAI
58305-24A20
HYUNDAI
58305-25000
KASHIYAMA
K11155
KASHIYAMA
K11162
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
04.94~08.99 1300 G4EH X3 RN1027V PN0091 DN1469DN1466 FN11162
04.94~08.99 1500 G4EK 4DR SDN LHD RN1027V PN0091 DN1466DN1469 FN11162
04.94~08.99 1500 G4EK 4DR SDN RHD RN1027V PN0091 DN1466DN1469 FN11162
04.94~08.99 1500 G4EK 5DR HB LHD RN1027V PN0091 DN1466DN1469 FN11162
04.94~08.99 1500 G4EK 5DR HB RHD RN1027V PN0091 DN1466DN1469 FN11162
09.97~09.03 1000 G4HC GEX02 RHD PN0109PN0439 DN1452 FN11162
09.97~09.03 1000 G4HC GEX06 LHD PN0439PN0109 DN1452 FN11162
12.06~01.11 1000 G4HC PRIME RHD PN0439 DN1513 FN11162
01.03~ 1100 G4HD MX PN0439 DN1513 FN11162
01.01~ 1100 G4HG PRIME PN0439 DN1452 FN11162
06.03~04.06 1500 G4EC XD SDN PN0542PN2245 DN1478 FN11162PN2130FN11158
09.94~01.00 1500 G4EK PN0091 FN11162
09.94~12.99 1300 G4EH X2 RN1027V PN0091 FN11162
09.94~12.99 1500 G4EK X2 RN1027V PN0091 FN11162
09.94~12.99 1500 G4EK X3 RN1027V PN0091 FN11162
09.92~06.96 1500 G4EK VE3N RN1027V PN0091 DN1500 FN11162
01.99~01.06 1000 G4HC 5 DR SEDAN DN1513 FN11162
01.98~10.14 1100 G4HG 5 DR SEDAN PN0439 DN1513 FN11162

Exemption from liability: the catalog data is advisory and can be used for reference only
