ROTOR DISC » RN1068V
Specification
Type
Vented
Disc Thickness (Max)
22
Num. of holes
4
Height
40.3
Centering Diameter
59
Front/Rear
Front
Pitch Circle Ø
98
Outter Ø
257.2
Drum Ø:
125
Disc Thickness (Min)
20
Structure Material
G3000
Cross Reference
ALFA ROMEO
46401356
ALFA ROMEO
46831041
BENDIX
562178B
CHRYSLER
05154237AA
CHRYSLER
K05154237AA
CITROEN
4249 74
FIAT
46401356
FIAT
46542383
FIAT
46831041
FIAT
5 189 6288
FIAT
51896287
FIAT
71739640
Peugeot / Citroen
4249 E5
Peugeot / Citroen
4249 L2
Peugeot / Citroen
4249.73
| years | Eng | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 08.08~06.11 | 1400 | 199.A8.000 | 955 | RN1068V | PN0211W | RN1869 | PN0515 | |
| 08.08~08.13 | 1400 | 955 A1.000 | 955 | RN1068V | PN0209W | RN1869 | PN0515 |
| 01.08~ | 1400 | 1.4 HDi 70 | Minivan | RN1068V | PN0211W | DN1562 | FN0624 | |
| 01.08~ | 1400 | DV4T | RN1068V | PN0211W | DN1562 | FN0682FN0624 |
| 01.07~01.12 | 1400 | 169 A3.000 | 150.045.0.5 | RN1068V | PN0211W | RN1385 | PN0197 | |
| 12.10~08.17 | 1400 | EAB | FF | RN1068V | PN0631W | RN1385 | PN41003 |
| 11.05~ | 1300 | 199 A2.000 | 223.317.2.0 | RN2026VRN1068V | PN0187PN0211W | DN1697 | FN41002 | |
| 01.05~01.16 | 1900 | 223 B1.000 | 223.313.2.0 | RN1068VRN2026V | PN0211WPN0187 | DN1697 | FN41002 |
| 01.07~01.16 | 1300 | 199 A2.000 | 2252L2051870 | RN1068V | PN0211W | DN1697 | FN0624 | |
| 05.14~ | 1400 | 327 A.011 | 87CV | RN1068V | PN0211W | FN0624 | ||
| 10.09~ | 1400 | 350 A1.000 | LCVs | RN1068V | PN0211W | DN1711 | FN0682 | |
| 01.08~ | 1400 | KFT | LCVs | RN1068V | PN0211W | DN1711 | FN0682 |
| 01.03~ | 1200 | RN1068V | PN0211W | |||||
| 01.03~ | 1300 | RN1068V | PN0211W | |||||
| 01.03~01.08 | 1400 | 843 A1.000 | 135.512.0.0 | RN1068V | PN0211W | DN1711 | FN0682 | |
| 01.03~ | 1900 | RN1068V | PN0187W | DN1697 |
| 02.12~ | 900 | 312 A# | 312 | RN1068V | PN41005 | RN1385 | FN0682PN41003 | |
| 09.03~08.13 | 1100 | 187 A1.000 | 169A | RN1068V | PN0287WPN0211W | RN1385DN1710DN1711 | FN0774PN0192FN0586FN0682FN0616 | |
| 03.10~08.13 | 1200 | 169 A4.000 | 169A | RN1068V | PN0287WPN0211W | RN1385DN1710DN1711 | PN0192FN0616FN0682FN0774FN0586 | |
| 12.03~12.06 | 1300 | 188 A9.000 | 169A | RN1068V | PN0287WPN0211W | DN1711DN1710RN1385 | FN0774FN0586FN0616PN0192FN0682 | |
| 02.12~ | 1300 | 199 A9.000 | 312 | RN1068V | PN41005 | RN1385 | PN41003 | |
| 10.06~08.13 | 1400 | 169 A3.000 | 169A | RN1068V | PN0211WPN0287W | RN1385DN1711DN1710 | FN0774FN0682PN0192FN0616FN0586 |
| 01.08~ | 1300 | RN1068V | PN0211W | FN0624 | ||||
| 01.08~ | 1400 | KFT | 255 | RN1068V | PN0211W | FN0624 | ||
| 01.09~ | 1400 | KFV | 255 | RN1068V | PN0211W | FN0682 | ||
| 01.07~01.16 | 1400 | KFV | 3002P1051870 | RN1068V | PN0211W | DN1711 | FN0682 |
| 10.01~10.03 | 1200 | 188 A5.000 | 192AXA1B | RN1068V | PN0211W | PN0515 | ||
| 10.01~10.03 | 1200 | 188 A5.000 | 192BXA1B | RN1068V | PN0211W | PN0515 | ||
| 08.03~ | 1400 | 843 A1.000 | 192AXH1B | RN1068V | PN0211W | PN0515 | ||
| 08.03~ | 1400 | 843 A1.000 | 192BXH1B | RN1068V | PN0211W | PN0515 | ||
| 08.03~ | 1400 | 843 A1.000 | 192CXH1B | RN1068V | PN0187W | PN0515 | ||
| 10.01~08.02 | 1600 | 182 B6.000 | 192AXB1 | RN1068V | PN0211W | PN0515 | ||
| 10.01~08.02 | 1600 | 182 B6.000 | 192BXB1 | RN1068V | PN0211W | PN0515 | ||
| 09.02~ | 1600 | 182 B6.000 | 192CXB1A | RN1068V | PN0187W | PN0515 | ||
| 10.01~08.02 | 1800 | 192 A4.000 | 192A | RN1068V | PN0187W | PN0515 | ||
| 10.01~08.02 | 1800 | 192 A4.000 | 192B | RN1068V | PN0187W | PN0515 | ||
| 10.01~08.02 | 1800 | 192 A4.000 | 192C | RN1068V | PN0187W | PN0515 | ||
| 10.01~08.02 | 1800 | 192 A4.000 | 192XC1 | RN1068V | PN0187W | PN0515 |
