DRUM BRAKE » DN1711
Specification
Outter Ø
249.5
Num. of holes
4
Hole Ø
13.2
Centering Diameter
59
Height
61
Pitch Circle Ø
139,7
Drum Ø
203.3
Structure Material
G3000
Cross Reference
FIAT
51822458
FIAT
51904079
FIAT
51904681
FIAT
51916180
FIAT
51945971
FIAT
51962845
FIAT
60813016
FIAT
7774593
| years | Eng | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 10.09~ | 1400 | 350 A1.000 | LCVs | RN1068V | PN0211W | DN1711 | FN0682 | |
| 01.08~ | 1400 | KFT | LCVs | RN1068V | PN0211W | DN1711 | FN0682 |
| 09.03~08.13 | 1100 | 187 A1.000 | 169A | RN1068V | PN0287WPN0211W | DN1710DN1711RN1385 | FN0682PN0192FN0586FN0616FN0774 | |
| 02.12~02.16 | 1200 | 1074374 | 312 | PN41005 | DN1711 | FN0682 | ||
| 03.10~08.13 | 1200 | 169 A4.000 | 169A | RN1068V | PN0287WPN0211W | DN1710DN1711RN1385 | FN0774FN0682PN0192FN0586FN0616 | |
| 12.03~12.06 | 1300 | 188 A9.000 | 169A | RN1068V | PN0287WPN0211W | DN1710DN1711RN1385 | FN0616FN0774FN0682PN0192FN0586 | |
| 10.06~08.13 | 1400 | 169 A3.000 | 169A | RN1068V | PN0287WPN0211W | DN1711RN1385DN1710 | FN0616PN0192FN0774FN0682FN0586 |
