BRAKE SHOE » FN0032
Specification
Radius
100
Width
30
Thickness
6.3
Pcs In Set
4
Cross Reference
AKEBONO
NN5523
BENDIX AUS
BS1682
BENDIX EUR
361841B
DAIHATSU
04495-87707
DAIHATSU
04495-87707-000
DAIHATSU
04495-87708
DAIHATSU
04495-87708-000
DAIHATSU
04495-87713-000
DAIHATSU
449587707
DAIHATSU
449587708
FMSI
S569
GM
91171399
GM
91177354
GM
91177391
KASHIYAMA
K0032
MAZDA
A050-26-310
MAZDA
A0Y8-26-310
SUZUKI
53200-50810
SUZUKI
53200-60840
SUZUKI
53200-60841
SUZUKI
53200-69G00
SUZUKI
53200-69G11
SUZUKI
53200-69G12
SUZUKI
53200-69G13
SUZUKI
53200-99G11
SUZUKI
5320069G10
SUZUKI
53210-50E10
SUZUKI
53210-70C00
SUZUKI
53210-70C10
SUZUKI
96066915
TOYOTA
53200-69G11
| years | Eng | Eng No | BodyBody | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 06.89~05.00 | 1600 | HD# | A101S JPN | PN6214 | DN1444 | FN0032 | ||
| 06.89~05.00 | 1600 | HD# | A101S RHD | PN6214 | DN1444 | FN0032 | ||
| 10.89~04.94 | 1600 | HD# | A111S | PN6214 | FN0032 |
| 11.01~03.07 | 1500 | M15A | RA21S | RN1205V | PN9461 | FN0032 | ||
| 01.01~06.06 | 1500 | M15A | RB21S | RN1205V | PN9461 | FN0032 | ||
| 01.03~03.07 | 1600 | M16A | RC31S JPN | RN1205V | PN9804 | DN1117 | FN0032 | |
| 06.03~12.07 | 1600 | M16A | RH416 | RN1205V | PN9461PN9804 | DN1117 | FN0032 | |
| 01.03~03.07 | 1800 | M18A | RC51S | RN1205V | PN9461 | FN0032 | ||
| 01.03~06.06 | 1800 | M18A | RD51S | RN1205V | PN9461 | FN0032 | ||
| 01.02~12.07 | 2000 | J20A | RC#1H | RN1205V | PN9461 | FN0032 | ||
| 11.03~01.08 | 2300 | J23A | RA62S SDN LHD | RN1205V | PN9461 | FN0032 | ||
| 01.02~01.08 | 2300 | J23A | RH423 | RN1205V | PN9461 | FN0032 |
| 03.90~09.91 | 660 | F6A# | CN21S | PN9213PN9183 | FN0032FN9931 | |||
| 03.90~09.91 | 660 | F6A# | CP21S | PN9213PN9182PN9183 | FN0032FN9928 |
| 01.95~12.02 | 1300 | G13BB | SY413 | RN1129V | PN9208 | DN1366 | FN0032 | |
| 01.95~01.03 | 1900 | #UD | SY419 | RN1129V | PN9381PN2356 | FN0032PN5198 |
| 11.96~03.98 | 1000 | G10A | SF310AA | PN9810PN9169 | FN0032FN9933 | |||
| 11.96~03.98 | 1000 | G10A | SF310MA | PN9169PN9810 | FN0032FN9933 | |||
| 06.88~05.00 | 1300 | G13B | AB34S | PN9208 | FN0032FN9933 | |||
| 10.89~05.00 | 1300 | G13B | AF34S | PN2367PN9208 | PN8076FN0032 | |||
| 01.92~05.00 | 1300 | G13B | AK34S | PN2367 | FN0032 | |||
| 01.95~01.01 | 1300 | G13B | GA11S | PN9208 | PN5198FN0032 | |||
| 11.96~03.98 | 1300 | G13BA | SF413MA | PN9810PN9169 | FN9933FN0032 | |||
| 07.91~03.95 | 1500 | G15A | AH64S | PN9169 | FN0032 | |||
| 07.91~03.95 | 1500 | G15A | AJ64S | PN9169 | FN0032 | |||
| 01.95~07.02 | 1500 | G15A | GC21S | PN9381 | FN0032 | |||
| 02.96~07.02 | 1500 | G15A | GC21W | PN9381 | FN0032 | |||
| 06.89~07.91 | 1600 | G16A | AH14S | PN9169 | FN0032 | |||
| 10.89~07.91 | 1600 | G16A | AJ14S | PN9169 | FN0032 | |||
| 02.96~01.01 | 1600 | G16A | GB31S | PN9381 | FN0032 | |||
| 02.96~05.98 | 1600 | G16A | GC31W | RN1129V | PN9381PN2356 | FN0032 | ||
| 02.96~08.02 | 1600 | G16A | GD31S | RN1129V | PN9381 | FN0032 | ||
| 02.96~07.02 | 1600 | G16A | GD31W | RN1129V | PN9381 | FN0032 |
| 01.95~05.99 | 1300 | G13B | GA11S | PN9208PN9381 | FN0032 | |||
| 01.95~02.96 | 1500 | G15A | GA21S | PN9381 | FN0032 | |||
| 01.95~02.96 | 1500 | G15A | GB21S | PN9381 | FN0032 | |||
| 01.95~11.02 | 1500 | G15A | GC21S | PN9381 | FN0032 | |||
| 01.95~02.96 | 1500 | G15A | GD21S | PN9381 | FN0032 | |||
| 02.96~07.02 | 1600 | G16A | GB31S | RN1129V | PN9381 | FN0032 | ||
| 02.96~08.02 | 1600 | G16A | GD31S | RN1129V | PN9381 | FN0032 | ||
| 02.96~07.02 | 1600 | G16A | GD31W | RN1129V | PN9381 | FN0032 |
| 03.01~12.07 | 1300 | M13A | ERA11S SDN | RN1205V | PN9804 | DN1117 | FN0032 | |
| 03.01~12.07 | 1300 | M13A | ERC11S HB | RN1205V | PN9804 | FN0032 | ||
| 01.01~01.08 | 1400 | 8HY | RH414 | PN9804PN9461 | FN0032 | |||
| 08.04~01.08 | 1600 | M16A | 2RC31S HB LHD | RN1205V | PN9461 | DN1117 | FN0032 | |
| 01.01~01.08 | 1600 | M16A | ERC31S HB | RN1205V | PN9804 | DN1117 | FN0032 | |
| 01.01~01.08 | 1800 | M18A | RH418 | PN9461PN9804 | FN0032 |
| 01.89~03.05 | 1000 | G10A | SF310 | PN9169 | DN1419DN1413DN1415 | FN0032FN9933 | ||
| 01.89~03.05 | 1300 | G13B# | SF413 | RN1296V | PN9810PN9807PN2367PN9169 | DN1415DN1419 | PN8076FN0032FN0632FN9933 | |
| 01.89~10.96 | 1600 | G16B | SF416 | RN1296V | PN9810PN9169PN2367 | DN1419 | FN0032 |
| 01.04~04.08 | 1300 | M13A | RS413-2 | RN2245V | PN9805 | DN1117 | FN0032 | |
| 11.04~09.10 | 1300 | M13A | ZD11S | RN2245V | PN9529 | FN9969FN0032 | ||
| 01.04~03.08 | 1500 | M15A | RS415-3 LHD | RN2245VRN1649V | PN9529 | RN1524DN1368 | PN8398FN9969FN0032 | |
| 03.08~01.11 | 1500 | M15A | RS415-4 LHD | RN2245VRN1649V | PN9529 | DN1368RN1524 | FN0032FN9969PN8398 | |
| 11.04~09.10 | 1500 | M15A | ZC21S | RN2245V | PN9529 | DN1368 | FN9969FN0032 | |
| 11.04~09.10 | 1500 | M15A | ZD21S | RN2245V | PN9529 | DN1117 | FN0032 | |
| 01.05~09.10 | 1600 | M16A | EZC31S | RN2245VRN1649VRN1525V | PN9529PN9805 | DN1117RN1524 | PN8398FN0032FN9969 | |
| 01.04~01.11 | 1600 | M16A | RS416 | RN2245V | PN9805 | RN1524 | PN8398FN0032 |
