DRUM BRAKE » DN1415

DN1415

Specification

Outter Ø
222
Num. of holes
4
Centering Diameter
45-47
Height
74.3
Pitch Circle Ø
114.3
Drum Ø
180
Hole Ø
12
Structure Material
G3000

Cross Reference

GM
91172152
GM
96062139
SUZUKI
43511-62B00
SUZUKI
43511-62B00-000
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

CHEVROLET (GM)   »   Geo Metro

10.89~09.01 1000 LP2 SF310 PN9169 DN1413DN1415DN1362 FN9933

SUZUKI   »   Swift

01.89~03.05 1000 G10A SF310 PN9169 DN1415DN1419DN1413 FN9933FN0032
01.95~01.06 1000 G10A SF310 PN9169 DN1415 FN9933
01.89~03.05 1300 G13B# SF413 RN1296V PN9810PN9807PN9169PN2367 DN1415DN1419 PN8076FN0032FN0632FN9933
