BRAKE SHOE » FN9931

Specification

Radius
90
Width
30
Thickness
6,5
Pcs In Set
4

Cross Reference

AKEBONO
NN-5521
KASHIYAMA
K9931
MAZDA
A001-26-31X
MAZDA
A001-26-32X
MAZDA
A001-26-38Z
SUZUKI
53200-70830
SUZUKI
53210-50E00
SUZUKI
53220-50E00
SUZUKI
53230-50E00
SUZUKI
53800-60800
SUZUKI
53820-60F00
SUZUKI
53820-70B00
SUZUKI
53830-60F00
SUZUKI
53830-70B00
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
10.89~02.90 550 F5B AA5PA PN9183PN9213 FN9931
02.90~10.95 660 F6A# AA6PA PN9183PN9213 FN9931FN0032
02.84~04.96 1000 EF10 KA6 PN2080PN7305 FN7728FN9931
04.89~03.90 550 F5B CN11S PN9183 FN9931
09.88~03.90 550 F5B# CL11V PN9183FN9915PN9213 FN9931
03.90~09.91 660 F6A CL21V PN9183 FN9931
09.91~11.94 660 F6A CL22V PN9183 FN9931
03.90~09.91 660 F6A# CN21S PN9213PN9183 FN0032FN9931
09.91~11.94 660 F6A# CR22S PN9213PN9183 FN9931PN9339
03.94~05.02 1000 G10B EFB11S PN9169 FN9931
11.90~09.91 660 F6A# CN21S PN9183 FN9931
09.91~10.95 660 F6A# CN22S PN9183PN9213PN9378 FN9931FN9944
07.90~09.91 660 F6B-T CN31S PN9213 FN0032FN9931
09.88~04.89 550 F5B CN11S PN9183 FN9931
09.93~10.95 660 F6A# CT21S PN9378PN9183PN9213 FN9931FN9944

Exemption from liability: the catalog data is advisory and can be used for reference only
