BRAKE SHOE » FN0715

Specification

Radius
106
Width
39
Thickness
5.7
Pcs In Set
4

Cross Reference

HYUNDAI
58350-3JA00
HYUNDAI
58350-4HA00
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
05.07~ 2400 G4KG TQ07 RN1457V PN0458 RN1656V PN0457 FN0715
05.07~08.15 2500 D4CB A2 TQ07 RN1457V PN0458 RN1656V PN0457 FN0715
05.07~08.15 2500 D4CB A2 WAGON LONG - 11P RN1457V PN0458 RN1656V PN0457 FN0715
01.18~ 2500 D4CB A2 WGN 11P LHD RN2433V PN0458 RN1656V PN0457 FN0715
08.15~12.17 2500 D4CB A2 WGN 12P LHD RN1457V PN0458 RN1656V PN0457 FN0715
01.18~ 2500 D4CB A2 WGN 12P LHD RN2433V PN0458 RN1656V PN0457 FN0715
08.15~12.17 2500 D4CB A2 WGN 12P RHD RN1457V PN0458 RN1656V PN0457FN11001 FN0715
12.17~ 2500 D4CB A2 WAGON LONG - 8P RN1457V PN0458 RN1656V PN0457 FN0715
05.07~08.15 2400 G4KG WAGON LONG - 12P LHD RN1457V PN0458 RN1656V PN0457 FN0715
05.07~08.15 2400 G4KG WAGON LONG - 12P RHD RN1457V PN0458 RN1656VDN1498 FN11001PN0457 FN0715
05.07~08.15 2500 D4CB A2 VAN LONG - 3P RN1457V PN0458 RN1656VDN1498 FN11002PN0457 FN0715
08.15~05.18 2500 D4CB A2 VAN LONG - 6P RN1457V PN0458 RN1656V PN0457 FN0715
05.07~08.15 2500 D4CB A2 WAGON LONG - 12P RN1457V PN0458 DN1498RN1656V FN11001PN0457 FN0715
08.15~05.18 2500 D4CB A2 WAGON LONG - 8P RN1457V PN0458 RN1656V PN0457 FN0715
10.06~01.14 3000 D6EA EN RN1349V PN0456 PN0457 FN0715
04.11~04.13 3000 D6EB EN07 PN0456 PN0457 FN0715
10.06~01.14 3800 G6DA EN PN0456 PN0457 FN0715
10.06~01.15 3000 D6EA EN07 RN1349V PN0456 PN0457 FN0715
10.06~01.15 3800 G6DA EN07 RN1349V PN0456 PN0457 FN0715
10.06~01.15 3800 G6DA EN07 GEN RN1349V PN0456 PN0457 FN0715

Exemption from liability: the catalog data is advisory and can be used for reference only
