ROTOR DISC » RN2537V

RN2537V

Specification

Type
Vented
Outter Ø
282
Num. of holes
5
Disc Thickness (Max)
27
Disc Thickness (Min)
25
Height
50.5
Hole Ø:
13.8
Centering Diameter
63.6
Pitch Circle Ø
108
Drum Ø:
139.8
Front/Rear
Front
Structure Material
G3000

Cross Reference

FORD
2 208 066
FORD
2 305 503
FORD
JX61-1125-AEA
FORD
JX61-1125-AEB
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

FORD   »   Focus IV

05.18~ 1500 C15DD0X CGE RN2537V PN0880 RN2368 PN0666

FORD   »   Focus IV Turnier

07.20~ 1000 C10FD0X HP RN2537V PN0880 RN2368 PN0666
