ROTOR DISC » RN2368

Specification

Type
Solid
Outter Ø
302
Num. of holes
5
Hole Ø:
13.8
Disc Thickness (Max)
11
Disc Thickness (Min)
9
Height
40.6
Centering Diameter
63.6
Pitch Circle Ø
108
Drum Ø:
185.5
Front/Rear
Rear
Structure Material
G3000

Cross Reference

FORD
1 936 154
FORD
2 210 993
FORD
G1FY-2A315-AA
FORD
JX61-2A315-BEA
FORD
LX6Z-2C026-B
FORD
LX6Z-2C026-C
FORD
LX6Z-2C026-D
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
08.19~ 1500 C15FDOS TC RN2367V PN0880 RN2368 PN0666
08.19~ 2000 C20HDTX TC RN2367V PN0880 RN2368 PN0666
08.19~ 2500 C25EDEF TC RN2367V PN0880 RN2368 PN0666
05.18~ 1500 C15DD0X CGE RN2537V PN0880 RN2368 PN0666
08.18~ 1500 C15FDOS CGE RN2367V PN0880 RN2368 PN0666
07.20~ 1000 C10FD0X HP RN2537V PN0880 RN2368 PN0666
08.18~ 1500 C15DD0X CGE RN2367V PN0880 RN2368 PN0666
08.18~ 1500 C15FDOS CGE RN2367V PN0880 RN2368 PN0666
01.20~ 1500 C15DDOX CTD RN2367V PN0880 RN2368 PN0666
01.20~ 1500 C15FDOS CTD RN2367V PN0880 RN2368 PN0666
01.20~ 2000 C20DDOJ CTD RN2367V PN0880 RN2368 PN0666
01.20~ 2500 C25EDEX CTD RN2367V PN0709 RN2368 PN0666
10.20~ 1500 ENY10 CDH RN2367V PN0880 RN2368 PN0666
10.20~ 2000 ENR90 CDH RN2367V PN0880 RN2368 PN0666
08.19~ 2000 C20HDTX TF RN2367V PN0880 RN2368 PN0666
08.19~ 2300 C23HDTX TF RN2367V PN0880 RN2368 PN0666

Exemption from liability: the catalog data is advisory and can be used for reference only
