ROTOR DISC » RN2367V

Specification

Type
Vented
Outter Ø
308
Num. of holes
5
Hole Ø:
13.8
Disc Thickness (Max)
27
Disc Thickness (Min)
25
Height
50.3
Centering Diameter
63.6
Pitch Circle Ø
108
Drum Ø:
140
Front/Rear
Front
Structure Material
G3000

Cross Reference

FORD
2 196 367
FORD
2 305 506
FORD
JX61-1125-BEB
FORD
LX6Z-1125-B
FORD
LX6Z-1125-E
FORD
LX6Z-1125-K
FORD
LX6Z-1125-L
FORD
LX6Z-1125-M
FORD
LX6Z-1125-N
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
08.19~ 1500 C15FDOS TC RN2367V PN0880 RN2368 PN0666
08.19~ 2000 C20HDTX TC RN2367V PN0880 RN2368 PN0666
08.19~ 2500 C25EDEF TC RN2367V PN0880 RN2368 PN0666
08.18~ 1500 C15FDOS CGE RN2367V PN0880 RN2368 PN0666
08.18~ 1500 C15DD0X CGE RN2367V PN0880 RN2368 PN0666
08.18~ 1500 C15FDOS CGE RN2367V PN0880 RN2368 PN0666
01.20~ 1500 C15DDOX CTD RN2367V PN0880 RN2368 PN0666
01.20~ 1500 C15FDOS CTD RN2367V PN0880 RN2368 PN0666
01.20~ 2000 C20DDOJ CTD RN2367V PN0880 RN2368 PN0666
01.20~ 2500 C25EDEX CTD RN2367V PN0709 RN2368 PN0666
10.20~ 1500 ENY10 CDH RN2367V PN0880 RN2368 PN0666
10.20~ 2000 ENR90 CDH RN2367V PN0880 RN2368 PN0666
08.19~ 2000 C20HDTX TF RN2367V PN0880 RN2368 PN0666
08.19~ 2300 C23HDTX TF RN2367V PN0880 RN2368 PN0666

Exemption from liability: the catalog data is advisory and can be used for reference only
