ROTOR DISC » RN2524V

RN2524V

Specification

Type
Vented
Outter Ø
312.5
Num. of holes
6
Hole Ø:
12.7
Disc Thickness (Max)
18
Disc Thickness (Min)
16
Height
80
Centering Diameter
101
Pitch Circle Ø
139.7
Front/Rear
Rear
Structure Material
G3000
Drum Ø:
204

Cross Reference

GREAT WALL
3502011-K00
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

Great Wall Motors   »   Hover H2

05.06~10.08 2400 4G64 H2 RN1395V PN0502 RN2524V PN4299 FN83001

Great Wall Motors   »   Hover H3

07.18~ 2000 4G63 H3NEW RN1395V PN0502 RN2524V PN4299
07.10~ 2000 4G63S4T H3 II PN8802 RN2524V PN4299

Great Wall Motors   »   Wingle 5

01.11~ 2000 GW4D20 CC1031PD RN1395V PN0502 RN2524V PN4299

Great Wall Motors   »   Wingle 6

01.14~12.21 2400 4G69S4N CC1031PB RN1395V PN0502 RN2524V PN4299

Great Wall Motors   »   Wingle 7

10.18~ 2000 GW4D20D CC1032PA RN1395V PN0502 DN1124RN2524V PN4299FN4467
