NiBK Brakes:: Application Cross Reference and Image for NiBK : BRAKE SHOE : FN0696

Product
Application

BRAKE SHOE » FN0696

Specification

Radius

94.5

Width

25

Thickness

3.5

Pcs In Set

2

Cross Reference

BENDIX AUS

BS3217

CHEVROLET

89047676

CHEVROLET (GM)

92511264

FMSI

S784-2199

FORD

7T4Z-2A753-A

FORD

AT4Z-2A753-A

FORD

BAF-2200-A

GM

12376595

GM

12455801

GM

12455804

GM

89047676

GM

92196003

GM

92511264

MAZDA

EGY3-44-39Z

MAZDA

EHY4-44-39Z

MAZDA

LFY4-44-39Z

SSANGYONG

4839205100

SSANGYONG

483KT05000

SSANGYONG

483KT05010

TOYOTA

04495-06050

years	Eng	Eng No	BodyBody	Front Rotor	Front Brake	Rear Rotor	Rear Brake	Parking Shoe

CADILLAC (GM) » SRX

09.03~12.09	3600	LY7	6EB26		PN0669		PN0625	FN0696
09.03~01.09	4600	LH2	6EB26		PN0669		PN0625	FN0696

CHEVROLET (GM) » Blazer

01.98~01.00

4300

L35

CT10506

PN0413

PN0414

FN0696

CHEVROLET (GM) » Caprice

01.14~01.17	6000	L77	1E#19 6G3#		PN0831		PN0832	FN0696
11.06~11.09	6000	L98	1EZ19 GCC		PN0831		PN0832	FN0696

CHEVROLET (GM) » Caprice / Lumina LHD

11.06~01.11	3600	LE0	8E##9	RN2420V	PN0831	RN2422V	PN0832	FN0696
01.11~01.14	6000	L77	1E#19 6G1#	RN2224V	PN0831 PN34002		PN0832	FN0696
01.07~12.09	6000	L98	8EP19	RN2224V	PN34002 PN0831		PN0832	FN0696

CHEVROLET (GM) » Corvette

10.96~08.04	5700	LS1	2DR COUPE		PN0613		PN0769	FN0696
09.04~12.07	6000	LS2	C6		PN0613		PN0769	FN0696
02.08~08.13	6200	LS3	C6		PN0613		PN0769	FN0696
01.06~02.13	7000	LS7	C6		PN0523			FN0696

CHEVROLET (GM) » Lumina

01.07~01.10

6200

LS3

8EK69

RN2420V

PN0831

PN0832

FN0696

CHEVROLET (GM) » SS

09.13~10.17

6200

LS3

EK69

PN0813S

PN0202W

FN0696

FORD » Edge

11.06~07.10

3500

T35PDED

TQ1

RN1503V

PN3813

PN5814

FN0696

FORD » Falcon

02.08~12.14	4000	BARRA 195	FG	RN2518V	PN0339 PN0826	RN2425	PN0202W PN0420 PN60001	FN0696
02.08~12.14	4000	BARRA 270	FG	RN2424V	PN0339 PN0826	RN2425	PN0202W PN0420 PN60001	FN0696

FORD » Territory

02.11~10.16	2700	276DT	SZ	RN2424V	PN0826		PN60001	FN0696
01.04~12.11	4000		TX	RN2424V	PN0826		PN60001	FN0696
02.11~10.16	4000	JGAT5R	SZ	RN2424V	PN0826		PN60001	FN0696

HOLDEN » Commodore

09.09~05.13	3000	LF1,LFW	VE	RN2420V	PN0831	RN2422V	PN0832	FN0696
05.13~10.17	3000	LFW	VF	RN2420V	PN0831	RN2422V	PN0832	FN0696
07.06~09.09	3600	LE0	VE	RN2420V	PN0831	RN2422V	PN0832	FN0696
09.09~05.13	3600	LFX	VE	RN2420V	PN0831	RN2422V	PN0832	FN0696
05.13~10.17	3600	LFX	VF	RN2420V	PN0831	RN2422V	PN0832	FN0696
09.09~05.13	3600	LY7	VE	RN2420V	PN0831	RN2422V	PN0832	FN0696
08.06~08.09	6000	L98 OHV	VE		PN0831		PN0832	FN0696
09.15~10.17	6200	LS3	VF		PN0813S		PN0202W	FN0696

LINCOLN » MKX

11.06~12.14

3500

T35PDED

Q1

RN1503V

PN3813

PN5814

FN0696

MAZDA » CX-7

06.09~12.12	2200	R2AA	AEES02	RN1503V	PN3813	RN1650V	PN5814	FN0696
05.07~06.09	2300	L3#	AEES01 EU JMZER	RN1501V RN1503V	PN3813	RN1502V	PN5814	FN0696
06.09~01.13	2300	L3-VDT	AEES02 EU JMZER	RN1501V	PN3813	RN1502V	PN5814	FN0696
02.06~01.15	2300	L3-VDT	AUES01 US JM3ER	RN1501V	PN3813	RN1502V	PN5814	FN0696
01.06~01.15	2300	L3-VDT	EG52 JM0ER	RN1501V	PN3813	RN1502V	PN5814	FN0696
01.07~01.15	2300	L3-VDT	ER3P	RN1501V	PN3813	RN1502V	PN5814	FN0696
04.09~01.15	2500	L5	ER	RN1501V	PN3813	RN1502V	PN5814	FN0696
08.09~01.15	2500	L5	ER19L	RN1501V	PN3813	RN1502V	PN5814	FN0696
06.09~12.12	2500	L5-VE	AEES02	RN1501V	PN3813	RN1502V	PN5814	FN0696

MAZDA » CX-9

10.06~12.15	3500	CYC4	TB	RN1503V	PN3813	RN1650V	PN5814	FN0696
10.06~07.09	3700	CAY	TV01	RN1503V	PN3813	RN1650V	PN5814	FN0696
07.09~12.12	3700	CAY	TV02	RN1503V	PN3813	RN1650V	PN5814	FN0696
11.12~12.15	3700	CAY	TV03	RN1503V	PN3813	RN1650V	PN5814	FN0696

MAZDA » MPV

01.06~04.16

2300

L3-V#

LY3P

RN1501V RN1503V

PN3813

RN1502V RN1650V

PN5814

FN0696

SSANGYONG » Actyon

10.05~01.11	2000	D20DT	C100	RN1620V	PN0103	DN1689 RN1657	PN0440 FN1879	FN0696
07.06~01.12	2300	G23D	C100 LHD	RN1620V	PN0103	RN1657 DN1689	PN0440 FN1879	FN0696
10.05~01.12	2300	G23D	C100 RHD	RN1620V	PN0103	DN1689 RN1657	PN0440 FN1879	FN0696

SSANGYONG » Actyon Sports

04.06~03.12	2000	D20DT	Q100 LHD	RN1620V	PN0103	RN1657 DN1689	PN0440 FN1879	FN0696
04.06~03.12	2000	D20DT	Q100 RHD	RN1620V	PN0103	RN1657 DN1689	FN1879 PN0440	FN0696

SSANGYONG » Actyon Sports II

03.12~	2000	D20DTR	Q150	RN1620V	PN0103	DN1689 RN1657	PN0440 FN1879	FN0696
07.16~	2200	D22DTR	Q160	RN1620V	PN0103	RN1657	FN1879 PN0440	FN0696
03.12~	2300	G23D	Q150	RN1620V	PN0103	DN1689 RN1657	PN0440 FN1879	FN0696

SSANGYONG » Korando

01.96~01.06

2300

OM 601.940

KJ

PN2245

RN1132

FN1879 PN0420 PN0440

FN0696

SSANGYONG » Kyron

01.05~01.15	2000	D20DT	5DR SUV	RN1620V	PN0103	RN1657 RN1798V DN1689	FN1879 PN0440	FN0696
04.07~01.12	2000	D20DT	5DR SUV DOM 7P	RN1620V	PN0103	DN1689 RN1657 RN1798V	PN0440 FN1879 PN0797	FN0696
01.05~01.15	2000	D20DT	5DR SUV EU	RN1620V	PN0103	RN1798V RN1657 DN1689	PN0440 FN1879	FN0696
01.05~01.15	2300	G23D	5DR SUV	RN1620V	PN0103	DN1689 RN1657	PN0440 FN1879	FN0750 FN0696
01.05~01.15	2700	D27DT	5DR SUV	RN1620V	PN0103	RN1798V DN1689	FN1879 PN0440	FN0696 FN0750

SSANGYONG » Musso

07.94~02.00	2300	OM 661	FJ	RN1145V	PN2245 PN0145W	RN1132	PN0420 FN1879	FN0696
09.02~04.06	2900	D29P/662LA	FJ	RN1145V	PN2245	DN1694 RN1132	PN0440	FN0696
06.98~06.05	2900	OM 662	FJ	RN1145V	PN2245	RN1132	PN0440 FN1879	FN0696

SSANGYONG » Rexton

05.12~10.17	2000	D20DTR	Y290	RN1620V	PN0103	RN1798V RN1657	PN0440 PN0797	FN0696
11.03~03.06	2700	D27DT	Y200	RN1145V	PN0103	RN1132	PN0440	FN0696
02.06~07.12	2700	D27DT	Y250	RN1620V	PN0103	RN1798V RN1657	PN0797 PN0440	FN0696
01.12~10.17	2700	D27DT	Y290	RN1620V	PN0103	RN1798V RN1657	PN0797 PN0440	FN0696 FN0750
10.02~03.06	2900	OM662L	Y200	RN1145V	PN0103 PN2245	DN1694 RN1132	PN0440 FN1879	FN0696
09.01~12.03	3200	G32D	Y200		PN2245	RN1132	FN1879 PN0440	FN0696

TOYOTA » Camry

01.06~09.11	2400	2AZ-FE	ACV40L	RN1241V	PN1521 PN0828	RN1943 RN1432	PN1522 PN0829	FN0633 FN0675
01.06~07.12	2400	2AZ-FE	ACV40R	RN1241V	PN0828 PN1521	RN1943 RN1432	PN0829 PN1522	FN0675
03.09~03.12	2400	2AZ-FE	AHV40R	RN1241V	PN1521	RN1432	PN1522	FN0675
09.11~06.17	2500	2AR-FE	ASV50L	RN1241V	PN1521	RN1432 RN1666	PN1522	FN0633 FN0675
03.12~11.18	2500	2AR-FXE	AVV50R	RN1241V	PN1521	RN1432	PN1522	FN0633 FN0675

TOYOTA » Camry/Aurion

08.11~10.17	2500	2AR-FE	ASV50L	RN1241V	PN0828 PN1521	RN1943 RN1432	PN1522 PN0829	FN0633 FN0675
10.11~10.17	2500	2AR-FE	ASV50R	RN1241V	PN1521 PN0828	RN1943	PN0829 PN1522	FN0675 FN0633
10.06~10.11	3500	2GR-FE	GSV40R	RN1241V	PN0828 PN1521	RN1943	PN0829 PN1522	FN0633 FN0675
