DRUM BRAKE » DN1694

DN1694

Specification

Outter Ø
296
Num. of holes
6
Centering Diameter
105.6
Height
87.7
Pitch Circle Ø
139.7
Drum Ø
254
Structure Material
G3000
Hole Ø
16
Notes
Tongil Axle

Cross Reference

SSANGYONG
4705917753
SSANGYONG
4831105600
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

SSANGYONG   »   Musso

09.02~04.06 2900 D29P/662LA FJ RN1145V PN2245 DN1694RN1132 PN0440 FN0696

SSANGYONG   »   Rexton

10.02~03.06 2900 OM662L Y200 RN1145V PN0103PN2245 RN1132DN1694 PN0440FN1879 FN0696
