ROTOR DISC » RN1503V

RN1503V

Specification

Type
Vented
Disc Thickness (Max)
28
Num. of holes
5
Height
48.5
Centering Diameter
72
Pitch Circle Ø
114.3
Outter Ø
320
Front/Rear
Front
Drum Ø:
142
Disc Thickness (Min)
26
Structure Material
G3000

Cross Reference

FORD
7T4Z-1125-A
FORD
7U2Z-1V125-ED
FORD
G2MZ-1V125-SA
MAZDA
EH14-33-25XA
MAZDA
L232-33-25XA
MAZDA
L232-33-25XB
MAZDA
TD133325X
OEM
EH143325X
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

FORD   »   Edge

08.11~12.14 2000 T20HDTX TQ1 RN1503V PN3813 RN1676 PN0698
11.06~07.10 3500 T35PDED TQ1 RN1503V PN3813 PN5814 FN0696
07.10~12.14 3500 T35PDED TQ1 RN1503V PN3813 RN1676 PN0698

LINCOLN   »   MKX

11.06~12.14 3500 T35PDED Q1 RN1503V PN3813 PN5814 FN0696
07.10~12.14 3700 T37PDED Q1 RN1503V PN3813 RN1676 PN0698

MAZDA   »   CX-7

06.09~12.12 2200 R2AA AEES02 RN1503V PN3813 RN1650V PN5814 FN0696
05.07~06.09 2300 L3# AEES01 EU JMZER RN1501VRN1503V PN3813 RN1502V PN5814 FN0696

MAZDA   »   CX-9

10.06~12.15 3500 CYC4 TB RN1503V PN3813 RN1650V PN5814 FN0696
10.06~07.09 3700 CAY TV01 RN1503V PN3813 RN1650V PN5814 FN0696
07.09~12.12 3700 CAY TV02 RN1503V PN3813 RN1650V PN5814 FN0696
11.12~12.15 3700 CAY TV03 RN1503V PN3813 RN1650V PN5814 FN0696

MAZDA   »   MPV

01.06~04.16 2300 L3-V# LY3P RN1503VRN1501V PN3813 RN1502VRN1650V PN5814 FN0696
