NiBK Brakes:: Application Cross Reference and Image for NiBK : ROTOR DISC : RN1914

Product
Application

ROTOR DISC » RN1914

Specification

Type

Solid

Outter Ø

324

Num. of holes

6

Disc Thickness (Max)

12

Height

69.5

Centering Diameter

96.3

Pitch Circle Ø

139.6

Drum Ø:

210

Front/Rear

Rear

Structure Material

G3000

Disc Thickness (Min)

10.4

Hole Ø:

12.5

Cross Reference

KIA

58411-4D000

years	Eng	Eng No	BodyBody	Front Rotor	Front Brake	Rear Rotor	Rear Brake	Parking Shoe

KIA » Carnival / Sedona 06

01.10~11.14	2200	D4HB	WAGON LONG - 11P	RN2609V	PN0588	RN1914	PN0457	FN0689
09.05~10.06	2900	J3	K4D005	RN1915V	PN0458	RN1914	PN0457	FN0689
11.06~10.14	2900	J3	WAGON LONG - 11P RHD	RN2609V	PN0588	RN1914	PN0457	FN0689
11.06~01.14	2900	J3	WAGON LONG - 8P	RN1915V	PN0588 PN0458	RN1914	PN0457	FN0689
01.06~01.14	3500	G6DC	WAGON LONG - 8P	RN1915V	PN0458	RN1914	PN0457	FN0689
