NiBK Brakes:: Application Cross Reference and Image for NiBK : ROTOR DISC : RN2609V

Product
Application

ROTOR DISC » RN2609V

Specification

Type

Vented

Outter Ø

325

Num. of holes

6

Disc Thickness (Max)

30

Disc Thickness (Min)

28

Height

54

Centering Diameter

96.3

Pitch Circle Ø

139.7

Front/Rear

Front

Structure Material

G3000

Hole Ø:

12.5

Cross Reference

HYUNDAI / KIA

51712-4D100

HYUNDAI / KIA

51712-4D300

years	Eng	Eng No	BodyBody	Front Rotor	Front Brake	Rear Rotor	Rear Brake	Parking Shoe

KIA » Carnival / Sedona 06

01.10~11.14	2200	D4HB	WAGON LONG - 11P	RN2609V	PN0588	RN1914	PN0457	FN0689
11.06~10.14	2900	J3	WAGON LONG - 11P RHD	RN2609V	PN0588	RN1914	PN0457	FN0689
