ROTOR DISC » RN1678V
Specification
Type
Vented
Front/Rear
Front
Num. of holes
6
Outter Ø
330
Disc Thickness (Max)
30
Centering Diameter
78.5
Drum Ø:
183
Height
55.7
Pitch Circle Ø
139.7
Disc Thickness (Min)
28
Structure Material
G3000
Cross Reference
CHEVROLET (GM)
15125955
CHEVROLET (GM)
88963556
GM
22950036
GM
23144340
GM
25819670
| years | Eng | Eng No | BodyBody | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 09.14~08.20 | 6200 | L86 | TK15706 | RN1678V | PN0400 | RN1757V | PN0657 | FN0741 |
| 10.06~08.08 | 6200 | L92 | TK10706 | RN1678V | PN0400 | RN1757V | PN51013 | FN0705 |
| 10.09~08.14 | 6200 | L94 | TC10706 | RN1678V | PN0400 | RN1757V | PN51013 | FN0705 |
| 10.09~08.14 | 6200 | L9H | TK10706 | RN1678V | PN0400 | RN1757V | PN51013 | FN0705 |
| 09.14~08.20 | 6200 | L86 | TK15906 | RN1678V | PN0400 | RN1757V | PN0657 | FN0741 |
| 10.06~08.08 | 6200 | L92 | TK10906 | RN1678V | PN0400 | RN1757V | PN51013 | FN0705 |
| 10.06~08.08 | 6200 | L92 | TK10936 | RN1678V | PN0400 | RN1757V | PN51013 | FN0705 |
| 10.06~08.14 | 6200 | L94 | 57C | RN1678V | PN0400 | RN1757V | PN51013 | FN0705 |
| 10.15~09.19 | 5300 | L83 | CK15543 | RN1678V | PN0400 | RN1757V | PN0657 | FN0741 |
| 01.02~01.07 | 5300 | LM7 | CC15543 | RN1678V | PN0400 | DN1682 | ||
| 12.06~04.13 | 5300 | LY5 | GMT900 | RN1678V | PN0400 | DN1682 | PN51013 | |
| 01.03~01.07 | 6000 | LQ9 | 1500 | RN1678V | PN0400 | DN1682 | ||
| 10.15~09.19 | 6200 | L86 | GMTK2 | RN1678V | PN0400 | RN1757V | PN0657 | FN0741 |
| 01.14~03.20 | 5300 | L83 | CK15906 | RN1678V | PN0400 | RN1757V | PN0657 | FN0741 |
| 07.06~06.14 | 5300 | LC9 | CK10906 | RN1678V | PN0400 | RN1757V | PN51013 | FN0705 |
| 07.06~06.14 | 5300 | LMG | C10906 | RN1678V | PN0400 | RN1757V | PN51013 | FN0705 |
| 07.14~06.20 | 5300 | L83 | C#15706 GL | RN1678V | PN0400 | RN1757V | PN0657 | FN0741 |
| 07.14~06.20 | 5300 | L83 | CK15706 US | RN1678V | PN0400 | RN1757V | PN0657 | FN0741 |
| 12.06~10.13 | 5300 | LMG | CK10706 | RN1678V | PN0400 | RN1757V | PN51013 | FN0705 |
| 01.07~04.14 | 6000 | LFA | CK10706 | RN1678V | PN0400 | RN1757V | PN51013 | FN0705 |
| 10.15~12.19 | 6200 | K2UXX | RN1678V | PN0400 | RN1757V | PN0657 | FN0741 |
