DRUM BRAKE » DN1682

Specification

Outter Ø
336
Num. of holes
6
Hole Ø
16.3
Centering Diameter
78.6
Height
96.5
Pitch Circle Ø
139.7
Drum Ø
295
Structure Material
G3000

Cross Reference

BENDIX
PDR0855
CHEVROLET
25976967
GM
19133374
GM
22874950
GM
25976967
GM
89059149
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
12.06~04.13 5300 LY5 GMT900 RN1678V PN0400 DN1682 PN51013
01.02~01.07 5300 LM7 CC15543 RN1678V PN0400 DN1682
12.06~04.13 5300 LY5 GMT900 RN1678V PN0400 DN1682 PN51013
01.03~01.07 6000 LQ9 1500 RN1678V PN0400 DN1682
02.98~12.07 4800 LR4 TC15703 RN1678V PN0400 DN1682

Exemption from liability: the catalog data is advisory and can be used for reference only
