NiBK Brakes:: Application Cross Reference and Image for NiBK : ROTOR DISC : RN2391V

Product
Application

ROTOR DISC » RN2391V

Specification

Type

Vented

Outter Ø

300

Num. of holes

6

Disc Thickness (Max)

27

Height

61

Centering Diameter

104.1

Disc Thickness (Min)

25

Front/Rear

Front

Structure Material

G3000

Pitch Circle Ø

139.7

Hole Ø:

14.2

Drum Ø:

175

Cross Reference

GM

52108355

years	Eng	Eng No	BodyBody	Front Rotor	Front Brake	Rear Rotor	Rear Brake	Parking Shoe

CHEVROLET (GM) » Colorado

01.17~	2500	LKH	12L43 LHD	RN2391V	PN2808	DN1440	FN6741
01.17~	2500	LKH	12L43 RHD	RN2391V	PN2808	DN1440	FN6741
01.17~	2500	LP2	LT#	RN2391V	PN2808	DN1440	FN6741
01.17~01.21	2800	LWN	LT#	RN2391V	PN2808	DN1440	FN6741

CHEVROLET (GM) » TrailBlazer

01.17~	2800	LWN	12S06 GL LHD	RN2391V	PN2808	RN1636V	PN28002
01.15~	2800	LWN	12S06 GR RHD	RN2391V RN1635V	PN0822 PN2808	RN1636V	PN28002
05.20~	3600	LFX	12S06	RN2391V	PN2808	RN1636V	PN28002
