NiBK Brakes:: Application Cross Reference and Image for NiBK : ROTOR DISC : RN1636V

Product
Application

ROTOR DISC » RN1636V

Specification

Type

Vented

Outter Ø

318

Num. of holes

6

Disc Thickness (Max)

18

Height

80.2

Centering Diameter

101

Pitch Circle Ø

139.7

Front/Rear

Rear

Drum Ø:

210

Disc Thickness (Min)

16.6

Structure Material

G3000

Cross Reference

GM

52032731

GM

98115794

ISUZU

8-98115-794-1

ISUZU

8981157940

years	Eng	Eng No	BodyBody	Front Rotor	Front Brake	Rear Rotor	Rear Brake	Parking Shoe

CHEVROLET (GM) » TrailBlazer

01.12~	2500	LVN	12S06	RN1635V	PN0822	RN1636V	PN28002	FN0734
08.16~	2500	XLD25	31UX	RN1635V	PN0822	RN1636V	PN28002	FN0734
01.12~	2800	LWH	31UX	RN1635V	PN0822	RN1636V	PN28002	FN0734
01.17~	2800	LWN	12S06 GL LHD	RN2391V	PN2808	RN1636V	PN28002
01.15~	2800	LWN	12S06 GR RHD	RN2391V RN1635V	PN0822 PN2808	RN1636V	PN28002
01.15~	3600	LFX	12S06	RN1635V	PN0822	RN1636V	PN28002
05.20~	3600	LFX	12S06	RN2391V	PN2808	RN1636V	PN28002
03.12~	3600	LY7	12S06	RN1635V	PN0822	RN1636V	PN28002	FN0734

ISUZU » MU-X

01.14~12.15	2500	4JJ1-TCX	UCS85	RN1635V	PN0822	RN1636V	PN28002	FN0734
01.17~12.17	2500	4JK1-TCX	UCR86	RN1635V	PN0822	RN1636V	PN28002	FN0734
03.17~11.20	2500	4JK1-TCX	UCS86 RHD MLY	RN1635V	PN0822	RN1636V	PN28002	FN0734
10.18~11.20	3000	4JJ1-TCX	UCS85	RN1635V	PN0822	RN1636V	PN28002	FN0734
