DRUM BRAKE » DN1440
Specification
Outter Ø
337
Num. of holes
6
Centering Diameter
101
Height
80.4
Pitch Circle Ø
139.7
Drum Ø
295
Structure Material
G3000
Hole Ø
12.5
Cross Reference
GM
94726742
ISUZU
8-97948-038-0
ISUZU
8-97948-038-1
ISUZU
8-98061-813-0
ISUZU
8-98061-813-1
| years | Eng | Eng No | BodyBody | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 01.17~ | 2500 | LKH | 12L43 LHD | RN2391V | PN2808 | DN1440 | FN6741 | |
| 01.17~ | 2500 | LKH | 12L43 RHD | RN2391V | PN2808 | DN1440 | FN6741 | |
| 01.14~01.17 | 2500 | LKH | LT# | RN1327VRN1635V | PN0822 | DN1440 | FN6741 | |
| 01.17~ | 2500 | LP2 | LT# | RN2391V | PN2808 | DN1440 | FN6741 | |
| 01.12~12.14 | 2500 | LVN | S10 | RN1327V | PN0822 | DN1440 | FN6741 | |
| 01.09~01.16 | 2800 | LWH | LT# | RN1635V | PN0822 | DN1440 | FN6741 | |
| 01.12~01.17 | 2800 | LWN | LT# | RN1635V | PN0822 | DN1440 | FN6741 | |
| 01.17~01.21 | 2800 | LWN | LT# | RN2391V | PN2808 | DN1440 | FN6741 | |
| 01.12~01.17 | 3600 | LY7 | LT# | RN1327VRN1635V | PN0822 | DN1440 | FN6741 |
| 06.12~ | 2500 | 4JK1-TCY | TFR86 | RN1635V | PN0822 | DN1440 | FN6741 | |
| 06.12~ | 2500 | 4JK1-TCY | TFS86 | RN1635V | PN0822 | DN1440 | FN6741 |
| 06.12~12.13 | 2500 | LVN | RG | RN1635V | PN0822 | DN1440 | FN6741 | |
| 06.12~12.20 | 2800 | LWH | RG | RN1635V | PN0822PN2808 | DN1440 | ||
| 11.12~12.20 | 2800 | LWN | RG | RN1635V | PN2808PN0822 | DN1440 | FN6741 |
| 09.19~ | 1900 | RZ4E-TC | TFS87 ML RHD | RN2633V | PN2401PN2402 | DN1440 | FN6741 | |
| 01.16~ | 1900 | RZ4E-TC | TF_87 | PN2403 | DN1440 | FN6741 | ||
| 02.17~ | 1900 | RZ4E-TCX | TFR87 | RN1327V | PN0822 | DN1440 | FN6741 | |
| 02.17~ | 1900 | RZ4E-TCX | TFS87 | RN2416V | PN2401 | DN1440 | FN6741 | |
| 11.19~ | 2500 | 4JK1-TCS | TFR86 INDIA LHD | RN1327V | PN0822 | DN1440 | FN6741 | |
| 10.16~ | 2500 | 4JK1-TCX | TFR86 RHD | RN1635V | PN0822 | DN1440 | FN6741 | |
| 01.16~10.19 | 2500 | 4JK1-TCX | TFS86 | RN1635V | PN0822 | DN1440 | FN6741 | |
| 03.12~01.16 | 2500 | 4JK1-TCX | TFS86 LA RHD | RN1635V | PN0822 | DN1440 | FN6741 | |
| 01.17~ | 2500 | 4JK1-TCX | TFS86 LHD | RN1635V | PN0822 | DN1440 | FN6741 | |
| 10.18~ | 2500 | 4JK1-TCX | TFS86 LHD | RN1635V | PN0822 | DN1440 | FN6741 | |
| 09.15~ | 2500 | 4JK1-TCX | TF_86 | RN1635V | PN0822 | DN1440 | FN6741 | |
| 01.16~10.19 | 2500 | 4JK1-TCX | TGS86 INDIA | PN2403 | DN1440 | FN6741 | ||
| 03.12~ | 2500 | 4JK1-TCY | TFS86 EU RHD | RN1635V | PN0822 | DN1440 | FN6741 | |
| 03.12~ | 2500 | 4JK1-TCY | TFS86 ML RHD | RN1635V | PN0822 | DN1440 | FN6741 | |
| 01.13~12.16 | 3000 | 4JJ1-T | TFS85JDR | RN1635V | PN0822 | DN1440 | FN6741 | |
| 06.12~05.17 | 3000 | 4JJ1-TCS | TFS85J LHD | RN1635V | PN0822 | DN1440 | FN6741 | |
| 06.12~ | 3000 | 4JJ1-TCX | TFR85 | RN1635V | PN0822 | DN1440 | FN6741 | |
| 01.16~ | 3000 | 4JJ1-TCX | TFS6WF | RN1635V | PN0822 | DN1440 | FN6741 | |
| 01.17~ | 3000 | 4JJ1-TCX | TFS85JDL | RN1635V | PN0822 | DN1440 | FN6741 | |
| 07.20~ | 3000 | 4JJ3-TCX | TFS40 RHD | RN2633VRN2416V | PN2402PN2401 | DN1440 | FN6741 |
