DRUM BRAKE » DN1418

DN1418

Specification

Outter Ø
311
Num. of holes
6
Hole Ø
12.5
Centering Diameter
93
Height
76.5
Pitch Circle Ø
139.7
Drum Ø
260
Structure Material
G3000

Cross Reference

HYUNDAI / KIA
0S08326251B
HYUNDAI / KIA
0S08326251D
KIA
0S08326251C
MAZDA
S083-26-251B
MAZDA
S083-26-251C
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

KIA   »   Besta

07.92~12.03 2200 R2 PN5211 DN1418 FN3349

KIA   »   Pregio / Besta

01.00~01.06 2700 J2 TB241 LONG LHD VAN PN0671 DN1418 FN3349
01.00~12.05 2700 J2 TR731 LONG RHD WGN PN0671 DN1418 FN3349
01.97~11.03 3000 JT TR732 PN0671 DN1418 FN3349

MAZDA   »   B1800

03.96~08.99 1800 F8 UF PN5297PN5804 DN1418 FN3378

MAZDA   »   B2200

01.85~02.99 2200 F2 UF PN5297 DN1418DN1411 FN3357FN3378
01.85~02.99 2200 R2 UF PN5297 DN1418DN1411 FN3357FN3378

MAZDA   »   B2500

03.96~02.99 2500 WL ABUA03 PN5334 DN1418 FN3378

MAZDA   »   B2600

01.85~02.99 2600 G6 UF PN5297PN0179PN5804 DN1418DN1411 FN3357FN3378

MAZDA   »   BT-50

09.06~09.11 2200 F2 UN RN1465VRN1806V PN5800PN0163PN5804 DN1748DN1101DN1418 FN3378FN3416FN3413
07.08~09.12 2500 WLAA UN RN1806VRN1465V PN0163PN5804PN5800 DN1418DN1748DN1101 FN3413FN3378FN3416
09.06~07.08 2600 G6-E ALUA07 RN1806VRN1465V PN0163PN5804PN5800 DN1418DN1748DN1101 FN3378FN3416FN3413
08.06~09.11 3000 WEAT ALUA07 RN1465VRN1806V PN5800PN0163PN5804 DN1101DN1418DN1748 FN3416FN3413FN3378

MAZDA   »   E2000

01.84~08.99 2000 FE SD PN5211 DN1418 FN3349

MAZDA   »   Proceed

02.96~02.99 2500 G5-E UV56R PN5334 DN1418 FN3378
11.89~02.99 2600 G6 UF66M PN5334PN5297 DN1418 FN3378
