ROTOR DISC » RN1465V
Specification
Type
Vented
Disc Thickness (Max)
28
Num. of holes
6
Height
70.5
Centering Diameter
98
Front/Rear
Front
Pitch Circle Ø
139.7
Outter Ø
289
Drum Ø:
163.5
Disc Thickness (Min)
26
Structure Material
G3000
Cross Reference
FORD
1 490 412
FORD
2M341027AA
FORD
4 429 562
FORD
6M341027AA
FORD
UM5133251
FORD
UR6133251
MAZDA
UM51-33-251
MAZDA
UR61-33-251
OEM
UMY133251
| years | Eng | Eng No | BodyBody | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 03.09~ | 2500 | 2.5 Diesel TI (HP) | EP | RN1465V | PN5800 | DN1101 | FN0637 | |
| 10.06~03.09 | 2500 | 2.5 Diesel TI (HP) | EU | RN1465V | PN5800 | DN1101 | FN0637 | |
| 04.03~10.07 | 2500 | 2.5 Diesel TI (HP) | EV | RN1465V | PN5800 | DN1101 | FN3416 | |
| 03.09~ | 2500 | 2.5l 16V DOHC HPCR DI TC | EP | RN1465V | PN5800 | DN1101 | FN0637 | |
| 04.03~10.07 | 2500 | 2.5l 16V DOHC HPCR DI TC | EV | RN1465V | PN5800 | DN1101 | FN3416 | |
| 10.06~03.09 | 3000 | 3.0 Diesel HPCR DI | EU | RN1465V | PN5800 | DN1101 | FN0637 | |
| 03.09~ | 3000 | 3.0l 16V DOHC HPCR DI TC | EP | RN1465V | PN5800 | DN1101 | FN0637 |
| 02.06~12.09 | 2200 | 2.2L EFI | ET | RN1806VRN1465V | PN5800PN0163 | DN1101DN1748 | FN0637FN0707FN3413 | |
| 06.02~10.07 | 2500 | 2.5 Diesel TI (HP) | EQ | RN2480VRN1465VRN1806V | PN0163 | DN1101DN1748 | FN3416FN3413 | |
| 05.06~12.11 | 2500 | 2.5 Diesel TI (HP) | MN#40 | RN1465VRN1806V | PN0163PN5800 | DN1748DN1101 | FN3413FN0637 | |
| 02.06~09.11 | 2500 | 2.5l 16V DOHC HPCR DI TC | ET | RN1465V | PN5800 | DN1101 | FN0707 | |
| 11.08~10.12 | 2500 | 2.5l 16V DOHC HPCR DI TC | WF#E10 LHD | RN1465V | PN5800 | DN1101 | FN0707 | |
| 11.08~10.12 | 2500 | WLAA | ES | RN1465V | PN5800 | DN1101 | FN0637 | |
| 01.09~10.12 | 2600 | 2.6L OHC EFI | ES | RN1465V | PN5800 | DN1101 | FN0637 | |
| 06.02~10.07 | 2900 | 2.9L SOHC NA I4 | MN#80 | RN1465VRN1806VRN2480V | PN5800PN0163 | DN1101DN1748 | FN3416 | |
| 11.08~10.12 | 3000 | MD30DITC | MN#90 RHD TH | RN1465V | PN5800 | DN1101 | FN0637 | |
| 02.06~11.08 | 3000 | WEAT | ET | RN1465V | PN5800 | DN1101 | FN0637 |
| 09.06~09.11 | 2200 | F2 | UN | RN1806VRN1465V | PN0163PN5804PN5800 | DN1418DN1748DN1101 | FN3413FN3378FN3416 | |
| 03.06~10.08 | 2500 | WLAA | AEUA06 | RN1465V | PN5800 | DN1101 | FN3416 | |
| 03.06~03.09 | 2500 | WLAA | ALUA07 | RN1465V | PN0163PN5804PN5800 | DN1748DN1101 | FN3413FN3416FN3378 | |
| 07.08~09.12 | 2500 | WLAA | UN | RN1465VRN1806V | PN0163PN5804PN5800 | DN1418DN1748DN1101 | FN3413FN3378FN3416 | |
| 09.06~07.08 | 2600 | G6-E | ALUA07 | RN1806VRN1465V | PN5800PN0163PN5804 | DN1101DN1418DN1748 | FN3413FN3378FN3416 | |
| 03.06~10.08 | 3000 | WEAT | ABUA07 MM0 | RN1465V | PN5800 | DN1101 | FN3416 | |
| 08.06~09.11 | 3000 | WEAT | ALUA07 | RN1465VRN1806V | PN0163PN5804PN5800 | DN1418DN1748DN1101 | FN3413FN3378FN3416 |
