ROTOR DISC » RN2480V

RN2480V

Specification

Type
Vented
Outter Ø
274
Num. of holes
6
Hole Ø:
10.6
Disc Thickness (Max)
24
Disc Thickness (Min)
22
Height
24
Centering Diameter
93
Pitch Circle Ø
116
Front/Rear
Front
Structure Material
G3000

Cross Reference

FORD
1 497 307
FORD
3 902 839
FORD
6M34-1027-EA
FORD
XM34-1027-BA
MAZDA
UH74-33-251
MAZDA
UN13-33-251
OEM
3902839
OEM
UH7433251
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

FORD   »   Ranger

06.02~10.07 2500 2.5 Diesel TI (HP) EQ RN2480VRN1465VRN1806V PN0163 DN1748DN1101 FN3416FN3413
09.02~10.07 2500 2.6L OHC EFI EQ RN2480V PN5800 DN1101 FN3416
06.98~07.03 2500 WL-T ER RN2480VRN1806V PN0163 DN1101DN1748 FN3416FN3413
06.02~10.07 2900 2.9L SOHC NA I4 MN#80 RN1806VRN2480VRN1465V PN0163PN5800 DN1748DN1101 FN3416

MAZDA   »   B2200

02.99~01.06 2900 W9 ALUA05 RN2480V PN0163 DN1101 FN3416

MAZDA   »   B2500

11.98~08.02 2500 WL ABUA4 ER RN1806VRN2480V PN0163 DN1748DN1101 FN3416FN3413
02.99~08.02 2500 WL AUEA4 RN1806VRN2480V PN0163 DN1101DN1748 FN3413FN3416
