DRUM BRAKE » DN1411

DN1411

Specification

Outter Ø
302
Num. of holes
6
Hole Ø
12.5
Centering Diameter
93
Height
70.4
Pitch Circle Ø
139.7
Drum Ø
260
Structure Material
G3000

Cross Reference

MAZDA
UB39-26-251
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

MAZDA   »   B2000

01.85~12.93 2000 FE UF PN5297 DN1411 FN3357

MAZDA   »   B2200

01.85~02.99 2200 F2 UF PN5297 DN1418DN1411 FN3357FN3378
01.85~02.99 2200 R2 UF PN5297 DN1411DN1418 FN3357FN3378

MAZDA   »   B2600

01.85~02.99 2600 G6 UF PN5297PN0179PN5804 DN1411DN1418 FN3357FN3378
