BRAKE SHOE » FN4443
Specification
Radius
95
Width
47
Thickness
4 / 6.2
Pcs In Set
2
Cross Reference
AKEBONO
NN4026
BENDIX AUS
BS1718
FMSI
S733-2183
HYUNDAI / KIA
59822-5HA20
ISUZU
8-94131881
ISUZU
8-94311-777-0
ISUZU
8-94311777
ISUZU
8-97020-250-2
ISUZU
8-97020250
ISUZU
8-97039-047-0
ISUZU
8-97039047
ISUZU
8970202501
ISUZU
SU00200286
KASHIYAMA
K4443
MAZDA
1K00-49-390
MITSUBISHI
MC894263
NISSAN
36160-89TA0
NISSAN
36160-89TA3
NISSAN
36160-WK625
OPEL
97020250
TOYOTA
46530-37040
TOYOTA
SU00200286
years | Eng | Eng No | BodyBody | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
---|
01.11~ | 4000 | N04C | XZU710R | RN1448V | PN1388PN4543 | RN1841V | PN4543 | FN4443 |
01.11~ | 4000 | N04C | XZU720L | RN2251V | PN4464 | RN2252V | PN4464 | FN4443 |
05.99~07.05 | 3700 | 4B | BU301M | PN1441PN1388 | FN2296FN2329BL2329 | FN0015FN4443 | ||
05.99~07.05 | 3700 | 4B | BU301X | PN1441PN1388 | FN2329FN2296BL2329 | FN4443FN0015 | ||
10.03~10.06 | 4000 | N04C | XZU304M | PN1388 | FN2329BL2329 | FN0015FN4443 | ||
07.11~ | 4000 | N04C-T | XZU710M | RN1448VRN2251V | PN1388PN4543 | RN1841VDN1424RN2252V | PN1388PN4543 | FN0015FN4443FN2320 |
07.11~ | 4000 | N04C-T | XZU710R | RN1448VRN2251V | PN1388PN4543 | RN2252VRN1841VDN1424 | PN4543PN1388 | FN4443FN0015FN2320 |
08.11~ | 4000 | N04C-T | XZU711 | RN1448VRN2251V | PN1388PN4543 | RN1841VDN1424RN2252V | PN1388PN4543 | FN0015FN2320FN4443 |
01.10~ | 3900 | D4DB | CNB04EM | FN0832 | DN1483 | FN0832 | FN4443 | |
01.04~01.10 | 3900 | D4DD | HD17PP | RN1629V | PN0417 | FN4443 |
01.04~01.09 | 3900 | D4DB | FGA17 RHD | FN0635PN0417 | FN0635 | FN4443 | ||
06.11~ | 3900 | D4DC11 | FGA17 RHD | FN0679FN0832 | FN0679FN0832 | FN4443 |
02.18~ | 2500 | 4JA1-T | PHR54 | PN0938 | DN1439 | FN4470 | FN4443 | |
09.19~ | 2500 | 4JA1-TC | PHR54 | PN0938 | DN1439 | FN4470 | FN4443 |
12.10~ | 3000 | 4JJ1-T | NLR85U RHD | DN1438 | FN4458 | FN4458 | FN4443 | |
01.08~01.10 | 3000 | 4JJ1-T | NNR85U | RN1639V | PN4464 | BL1055FN4461 | FN4443 | |
04.19~ | 3000 | 4JJ1-TCC | NMR85L | FN4458 | FN4458 | FN4443 | ||
01.20~ | 3000 | 4JJ1-TCC | NPR85L | FN4459BL1054 | BL1054FN4459 | FN4443 | ||
03.08~12.10 | 3000 | 4JJ1-TCC | N_R85L | DN1112 | BL1054FN4459 | FN4459 | FN4443 | |
10.08~ | 4600 | 4600 | NQR71 | BL1032FN4401 | FN4401 | FN4443 | ||
10.08~ | 4600 | 4HG1 | NMR71 RHD | FN4458 | FN4458 | FN4443 | ||
10.08~01.11 | 4600 | 4HG1 | NPR71 RHD | DN1111 | FN4451 | DN1427 | BL1055FN4451 | FN4443 |
06.13~ | 4600 | 4HG1 | NPR71 RHD | DN1112 | FN4459BL1054 | FN4459 | FN4443 | |
11.98~11.02 | 4600 | 4HG1 | NPR71PU | DN1112 | FN4459 | FN4459BL1054 | FN4443 | |
01.11~ | 4600 | 4HG1 | NPS71 LHD | FN4451BL1055 | BL1054FN4459 | FN4443 | ||
01.11~ | 4600 | 4HG1 | NPS71 RHD | FN4451BL1055 | FN4459BL1054 | FN4443 | ||
12.16~ | 4800 | 4HL1TC-N | NPR81U ML | DN1111DN1112 | FN4451BL1054FN4459 | DN1427 | FN4459FN4451BL1054BL1055 | FN4443 |
01.09~01.14 | 5200 | 4HK1-TCN | NPR75U | RN2301V | PN4491 | BL1032FN4401 | FN4443 | |
01.20~ | 5200 | 4HK1-TCN | NPR75U | BL1032FN4401 | FN4401 | FN4443 |
01.97~01.12 | 4300 | 4HF1 | NPR66 | DN1111 | BL1055 | DN1427 | BL1055 | FN4443 |
01.97~01.12 | 4300 | 4HF1 | NPR66G DUMP LHD | DN1112 | BL1054FN4459 | FN4459 | FN4443 |
02.07~ | 3000 | 4JJ1-T | LJR85N | PN4464PN4543 | FN4465 | FN4443 | ||
02.07~ | 3000 | 4JJ1-T | LLR85 | PN4543PN4464 | FN4461FN4451BL1055 | FN4443 | ||
02.07~ | 3000 | 4JJ1-T | LLS85 | PN4543PN4464 | BL1055FN4461FN4451 | FN4443 | ||
02.07~ | 3000 | 4JJ1-T | LMR85 | BL1054PN4543PN4464 | BL1055FN4451FN4459 | FN4443 | ||
06.04~ | 3100 | 4JG2 | LHS69 | PN4384 | FN4443 | |||
06.04~02.07 | 4600 | 4HG1 | LKR81 | PN4464PN4543 | FN4443 | |||
04.05~06.12 | 4600 | 4HV1 | LKR82 | FN4459PN4464BL1054 | FN4459 | FN4443 | ||
05.05~ | 4600 | 4HV1 | LPR82 | BL1054FN4459PN4464 | FN4459 | FN4443 | ||
06.04~02.07 | 4800 | 4HL1 | LKR81 | BL1054FN4459PN4543PN4464 | FN4451FN4459FN4461FN4465BL1055 | FN4443 | ||
06.04~02.07 | 4800 | 4HL1 | LPR81 | PN4464PN4491 | FN4443 | |||
06.04~02.07 | 4800 | 4HL1 | LPS81A | PN4491PN4464 | FN4443 | |||
06.04~02.07 | 4800 | 4HL1 | LPS81N | PN4491PN4464 | FN4443 |
06.97~04.99 | 2000 | 4G63 | FA500 | PN3346 | FN6655 | FN4443 | ||
06.97~04.99 | 2000 | 4G63 | FA510 | PN3347PN3346 | FN6655 | FN4443 | ||
06.97~04.99 | 2000 | 4G63 | FA580 | PN3346 | FN6655 | FN4443 | ||
06.97~04.99 | 2000 | 4G63 | FA590 | PN3346 | FN6655 | FN4443 | ||
11.96~04.99 | 2400 | 4G64 | FA523B | PN3346 | FN6655 | FN4443 | ||
05.99~01.06 | 2400 | 4G64 | FB523 | PN3346 | FN4447 | FN4443 | ||
11.96~04.99 | 2400 | 4G64-P | FC563B | PN3407 | BL1060FN6653 | FN4443 | ||
03.99~06.02 | 2400 | 4G64-P | FE533 | PN3407 | BL1060FN6653 | FN4443 | ||
03.99~06.02 | 2800 | 4M40 | FB51A | PN3347PN3349PN3346 | FN4447FN6655FN6602 | FN4443 | ||
10.93~05.99 | 3600 | 4D36 | FE516BC | RN1262V | PN3349BL1060FN6653 | FN6602 | FN4443 | |
10.93~05.99 | 3600 | 4D36 | FE516BT | RN1260V | PN3347 | FN6602 | FN4443 | |
10.93~04.99 | 3600 | 4D36 | FE536 | PN3349 | FN6602 | FN4443 | ||
10.96~04.99 | 3600 | 4D36 | FE566 | PN3407 | BL1060FN6653 | FN4443 | ||
04.95~05.99 | 3600 | 4D36 | FE636 | PN3349 | FN6602 | FN4443 | ||
02.98~03.02 | 3900 | 4D34 | FE639 LHD | RN1451V | PN3407 | RN1927V | PN3407 | FN4443 |
01.95~05.99 | 3900 | 4D34 | FE659 | FN3366 | FN4443 | |||
04.95~ | 3900 | 4D34 | FE659F | FN3366 | FN6703 | FN4443 | ||
10.96~05.99 | 3900 | 4D34 | FE669 | PN3349PN3407 | FN6653FN6602BL1060 | FN4443 | ||
01.05~ | 3900 | 4D34 | FE83P | BL1070PN3513FN6722 | FN6602FN6653BL1060 | FN4443 | ||
01.08~ | 3900 | 4D34 | FE84P | DN1881 | BL1060FN6653 | DN1881 | FN6653 | FN4443 |
07.04~07.05 | 3900 | 4D34 | FE84P LHD | BL1070FN6722 | FN6722BL1070 | FN4443 | ||
07.05~07.07 | 3900 | 4D34 | FE84P LHD | BL1070FN6722 | BL1070FN6722 | FN4443 | ||
01.05~03.13 | 3900 | 4D34 | FE85P | FN6722BL1070 | FN6722 | FN4443 | ||
10.93~05.99 | 3900 | 4D34-T | FE639 | RN1262V | PN3349 | FN6602 | FN4443 | |
04.95~04.04 | 3900 | 4D34-T | FE649 | RN2033VRN1451V | PN3407BL1060FN6653 | RN1927V | PN3407FN6653 | FN4443 |
10.93~05.99 | 4200 | 4D33 | FE507B | RN1263V | PN3349 | FN6602 | FN4443 | |
05.99~05.02 | 4200 | 4D33 | FE50CB | RN1263V | PN3349 | FN6602 | FN4443 | |
10.93~05.99 | 4200 | 4D33 | FE517BD | RN1262V | PN3349 | FN6602 | FN4443 | |
11.96~05.02 | 4200 | 4D33 | FE51C | PN3407PN3349 | FN6653FN6602BL1060 | FN4443 | ||
03.95~04.99 | 4200 | 4D33 | FE527 | PN3349 | FN6602 | FN4443 | ||
03.99~05.02 | 4200 | 4D33 | FE52C | PN3349 | FN6602 | FN4443 | ||
10.93~04.99 | 4200 | 4D33 | FE537 | RN1262V | BL1060FN6653PN3407PN3349 | FN6602BL1060FN6653 | FN4443 | |
11.96~05.02 | 4200 | 4D33 | FE53C | RN1449V | FN6653PN3407PN3349BL1060 | FN6602BL1060FN6653 | FN4443 | |
10.96~05.99 | 4200 | 4D33 | FE567 | PN3407FN6653PN3349BL1060 | FN6653FN6602 | FN4443 | ||
05.99~ | 4200 | 4D33 | FE637 AUS | DN1881 | FN6653BL1060 | FN6653 | FN4443 | |
10.93~05.99 | 4200 | 4D33 | FE637 JPN | PN3349BL1060FN6653 | FN6602FN6653 | FN4443 | ||
05.99~05.02 | 4200 | 4D33 | FE63C | FN6653PN3349BL1060PN3407 | FN6602FN6653 | FN4443 | ||
11.97~05.99 | 4200 | 4D33 | FE667 | PN3407PN3349 | FN6602BL1060FN6653 | FN4443 | ||
05.02~12.04 | 4200 | 4D33 | FE70C | PN3514 | FN6602 | FN4443 | ||
05.02~08.04 | 4200 | 4D33 | FE71C | RN1262V | PN3514 | FN6602 | FN4443 | |
06.07~01.19 | 4200 | 4D33 | FE71C (FD2/G.EXP) | FN6627FN6602 | FN4443 | |||
05.02~12.04 | 4200 | 4D33 | FE72C | RN1262V | PN3514 | FN6602 | FN4443 | |
05.02~12.04 | 4200 | 4D33 | FE73C | PN3514PN3513 | FN6653FN6602BL1060 | FN4443 | ||
05.02~12.04 | 4200 | 4D33 | FE82C | PN3514 | FN6602 | FN4443 | ||
06.02~05.11 | 4200 | 4D33 | FE83C | BL1060FN6653 | FN6653 | FN4443 | ||
02.07~ | 4200 | 4D33 | FE85C | FN6722BL1070 | FN6722 | FN4443 | ||
10.93~03.95 | 4200 | 4D33 | FG537 | FN6653BL1060 | FN6653 | FN4443 | ||
10.93~05.99 | 4600 | 4D35 | FE508 | PN3349 | FN6602 | FN4443 | ||
10.93~04.99 | 4600 | 4D35 | FE518 | PN3349 | FN6602 | FN4443 | ||
03.95~04.99 | 4600 | 4D35 | FE528 | PN3349 | FN6602 | FN4443 | ||
10.93~04.99 | 4600 | 4D35 | FE538E | RN1451V | PN3407 | FN6653BL1060 | FN4443 | |
04.95~05.99 | 4600 | 4D35 | FE548 | BL1060FN6653 | FN6653 | FN4443 | ||
10.96~04.99 | 4600 | 4D35 | FE568 | PN3407BL1060FN6653PN3349 | FN6653FN6602 | FN4443 | ||
11.93~05.99 | 4600 | 4D35 | FE638 | RN1262V | BL1060PN3349PN3407FN6653 | FN6653FN6602 | FN4443 | |
04.95~05.99 | 4600 | 4D35 | FE648 | FN6653BL1060 | FN6653 | FN4443 | ||
10.95~05.99 | 4600 | 4D35 | FE658 | FN4443 | ||||
11.97~05.99 | 4600 | 4D35 | FE668 | PN3349PN3407 | FN6602FN6653BL1060 | FN4443 | ||
10.93~04.99 | 4600 | 4D35 | FG538 | FN6653BL1060 | FN6653 | FN4443 | ||
11.93~08.99 | 4600 | 4D35 | FG638 | FN6653BL1060 | FN6653 | FN4443 | ||
05.99~05.02 | 4900 | 4M50 | FE63D | PN3349PN3407BL1060FN6653 | FN6653FN6602 | FN4443 | ||
03.02~11.14 | 4900 | 4M50-T | FE82DE | RN1262V | PN3513PN3572PN3514PN3571 | FN6602PN3513FN6653PN3514BL1060 | FN4443FN4466 | |
06.02~12.10 | 4900 | 4M50-T | FE83D | RN1451V | BL1060PN3513FN6653 | FN6653 | FN4466FN4443 | |
03.99~05.02 | 4900 | 4M50-T | FF63D | FN6602 | FN4443 | |||
06.02~11.10 | 4900 | 4M50-T | FF83D | FN6602 | FN4443 | |||
05.99~05.02 | 5200 | 4M51 | FE50E | PN3349RN1263V | FN6602 | FN4443 | ||
10.97~04.99 | 5200 | 4M51 | FE512 | PN3349 | FN6602 | FN4443 | ||
05.99~05.02 | 5200 | 4M51 | FE51E | PN3349RN1263VPN3407 | FN6602 | FN4443 | ||
06.00~06.02 | 5200 | 4M51 | FE51EB | RN1451V | PN3407 | FN6653BL1060 | FN4443 | |
05.99~05.02 | 5200 | 4M51 | FE52E | PN3349RN1263V | FN6602 | FN4443 | ||
10.97~05.99 | 5200 | 4M51 | FE532 | PN3407PN3349 | FN6602FN6653BL1060 | FN4443 | ||
01.99~08.02 | 5200 | 4M51 | FE53EB | PN3407 | BL1060FN6653 | FN4443 | ||
05.99~05.02 | 5200 | 4M51 | FE53EC | RN1262V | PN3349 | FN6602 | FN4443 | |
05.99~05.02 | 5200 | 4M51 | FE53EEV | RN1262V | PN3349 | FN6602 | FN4443 | |
05.99~05.02 | 5200 | 4M51 | FE53EEX | DN1881 | FN6653 | BL1060FN6653 | FN4443 | |
10.97~05.99 | 5200 | 4M51 | FE542 | BL1060FN6653 | FN6653 | FN4443 | ||
10.97~05.99 | 5200 | 4M51 | FE562 | RN1451V | PN3407 | FN6653BL1060 | FN4443 | |
03.99~05.02 | 5200 | 4M51 | FE59E | BL1060PN3349FN6653 | FN6602 | FN4443 | ||
03.99~06.02 | 5200 | 4M51 | FE62E | PN3407 | FN6602 | FN4443 | ||
10.97~05.99 | 5200 | 4M51 | FE632 | BL1060PN3349PN3407FN6653 | FN6653FN6602 | FN4443 | ||
05.99~05.02 | 5200 | 4M51 | FE63E | PN3407FN6653 | BL1060FN6653 | FN4443 | ||
11.97~05.99 | 5200 | 4M51 | FE642 | FN6653BL1060 | FN6653 | FN4443 | ||
11.97~05.99 | 5200 | 4M51 | FE652 | BL1070FN6722 | FN6722 | FN4443 | ||
11.97~05.99 | 5200 | 4M51 | FE662 | PN3407PN3349 | FN6653FN6602BL1060 | FN4443 | ||
05.99~05.02 | 5200 | 4M51 | FE69E | BL1060FN6653PN3349PN3407 | PN3407FN6653 | FN4443 | ||
05.02~12.04 | 5200 | 4M51 | FE70E | RN1451V | PN3513PN3514 | PN3513PN3514FN6653FN6602BL1060 | FN4443 | |
05.02~12.04 | 5200 | 4M51 | FE71E | PN3514PN3513 | PN3514PN3513FN6653FN6602BL1060 | FN4443 | ||
05.02~08.04 | 5200 | 4M51 | FE72E | RN1262V | PN3514PN3513 | FN6653FN6602BL1060 | FN4443 | |
05.02~12.04 | 5200 | 4M51 | FE73E | RN1451V | PN3513 | FN6653BL1060 | FN4443 | |
05.02~12.04 | 5200 | 4M51 | FE78E | PN3514 | FN6602 | FN4443 | ||
05.02~08.04 | 5200 | 4M51 | FE82E | RN1451V | PN3513BL1070 | DN1110 | FN6722 | FN4443 |
05.02~12.04 | 5200 | 4M51 | FE83E | RN1262V | FN6722BL1070PN3513 | BL1070FN6722 | FN4443 | |
05.02~12.04 | 5200 | 4M51 | FE88E | BL1060PN3513PN3514FN6653 | FN6653FN6602 | FN4443 | ||
03.99~06.02 | 5200 | 4M51 | FF63E | FN6602 | FN4443 | |||
06.02~12.04 | 5200 | 4M51 | FF83E | FN6602 | FN4443 | |||
03.99~07.02 | 5200 | 4M51 | FG53E | BL1060FN6653 | FN6653 | FN4443 | ||
03.99~07.02 | 5200 | 4M51 | FG63E | BL1060FN6653 | FN6653 | FN4443 | ||
03.99~07.02 | 5200 | 4M51 | FG68E | PN3407 | BL1060FN6653FN6602 | FN4443 | ||
05.02~08.04 | 5200 | 4M51 | FG70EB | PN3514PN3513 | FN6602FN6653BL1060 | FN4443 |
12.95~05.99 | 3900 | 4D34-T | FK603 | FN4443 |
02.07~01.13 | 3000 | 4JJ1-T | AKR85 | PN4464BL1054PN4543FN4459 | FN4451FN4459BL1055 | FN4443 | ||
06.95~06.02 | 3100 | 4JG2 | BKR69 | PN4384PN4288 | BL1055FN4428FN4451FN4458 | FN4443 | ||
05.95~07.02 | 4300 | 4HF1 | AKR66 | PN4384FN4451PN4288 | BL1055FN4425FN4428FN4451 | FN4443 | ||
05.95~07.02 | 4300 | 4HF1 | APR66 | FN4451PN4288 | FN4451BL1055FN4447 | FN4443 | ||
05.95~06.02 | 4300 | 4HF1 | BKR66 | FN4451PN4384PN4288 | BL1055FN4428FN4451 | FN4443 | ||
11.95~06.99 | 4300 | 4HF1 | BKS66 | PN4384 | FN4451BL1055 | FN4443 | ||
05.95~06.02 | 4300 | 4HF1 | BPR66 | PN4288FN4451 | FN4451BL1055 | FN4443 | ||
06.95~04.99 | 4300 | 4HF1 | KR66LR | FN4451 | BL1055FN4451 | FN4443 | ||
05.95~07.02 | 4600 | 4HG1 | AKR71 | FN4451FN4459BL1054 | BL1055FN4451FN4459 | FN4443 | ||
05.95~07.02 | 4600 | 4HG1 | APR71 | FN4451PN4288 | FN4425FN4451BL1055 | FN4443 | ||
05.95~06.99 | 4600 | 4HG1 | APS71 | FN4451 | FN4451BL1055 | FN4443 | ||
05.95~06.02 | 4600 | 4HG1 | BKR71 | FN4451PN4384PN4288 | BL1055FN4451 | FN4443 | ||
05.95~06.02 | 4600 | 4HG1 | BPR71 | PN4288FN4451 | FN4451BL1055 | FN4443 | ||
05.95~06.99 | 4800 | 4HE1-T | APR70 | PN4288FN4451 | BL1055FN4451 | FN4404FN4443 |
02.99~10.04 | 4200 | TD42 | BVW41 | PN4464 | BL1055FN4451 | FN4443 | ||
02.99~10.04 | 4200 | TD42# | BJW41 | PN4464 | FN4451BL1055 | FN4443 | ||
09.04~08.07 | 4900 | 4M50-T | AHW41 | PN4464 | FN6653BL1060FN0016 | FN4443 | ||
09.04~08.07 | 4900 | 4M50-T | AVW41 | PN2802 | FN6653BL1060 | FN4443 |
